Samsung NX10 - Page 22

SAMSUNG This Document can not be used without Samsung’s authorization 3-5
Exploded View and Parts List
Loc. No Parts No.. Description Q ty Available Remark
3-1 AD97-17729A ASSY-HOLDER MOUNT 1 X
3-2 6107-001777 SPRING CMOS ADJUST 3 X
3-3 AD97-17731A ASSY-CMOS 1 X
3-4 6001-002279 SCREW-MACHINE 3 X
3-5 AD41-01400A FPC_DIGTAL 1 O
3-6 AD41-01401A FPC_ANALOG 1 O
3-7 AD92-01021A MAIN PCB ASSY 1 O
3-8 6003-001692 SCREW-TAPTYPE 4 X
3-9 6003-001637 SCREW-TAPTYPE 1 X
3-10 6003-00175 SCREW-TAPTYPE 1 X
3-11 AD97-17728A MAIN ASSY 1 O
