Samsung NX10 Service Manual

SAMSUNG This Document can not be used without Samsung’s authorization 3-7
Exploded View and Parts List
Loc. No Parts No.. Description Q ty Available Remark
4-1 AD61-04057A
HOLDER MOUNT 1 O
4-2 AD61-04085A PLATE FRONT COVER SUPPORT 1 X
4-3 6003-001641 SCREW 1.7*3.5 PAN 2 X
4-4 AD61-04093A HOLDER BUTTON PREVIEW 1 O
4-5 6003-001641 SCREW 1.7*3.5 PAN 1 X
4-6 6107-002627 SPRING LENS UNLOCK B 1 X
4-7 6107-001782 SPRING LENS UNLOCK 1 X
4-8 AD66-00687A SHAFT LENS LOCK 1 X
4-9 AD61-04086A PLATE LENS LOCK 1 X
4-10 AD64-02623A BUTTON LENS UNLOCK 1 O
4-11 6031-001628 WASHER PLAIN 1 X
4-12 6107-001781 SPRING LENS DETECT PIN 1 X
4-13 AD66-00686A SHAFT LENS DETECT 1 X
4-14 AD61-04075A PLATE MOUNT SPRING 1 X
4-15 AD61-04135A MOUNT LENS 1 O
4-16 6003-001755 SCREW 2.0*6.0 PAN 4 X
4-17 AD92-01023A STROBO PCB ASSY 1 O
4-18 6003-001641 SCREW 1.7*3.5 PAN 2 X
4-19 AD97-17730A ASSY-BASE IF PIN 1 O
4-20 6003-001641 SCREW 1.7*3.5 PAN 2 X
4-21 AD97-17601A SHUTTER ASSY 1 X
4-22 6003-001641 SCREW 1.7*3.5 PAN 2 X
4-23 AD97-17796A ASSY-CMOS BASE PLATE 1 X
4-24 2401-004660 C-AL 1 X
4-25 AD41-01405A CONDENSOR PCB 1 X
4-26 3003-001159 MIC-CONDENSOR 1 O
4-27 AD73-00367A RUBBER-MIC 1 O
4-28 AD63-04413A TAPE MAIN FRAME A 2 X
4-29 AD63-04555A CUSHION SHIELD FOAM JACK 2 X
4-30 6003-001641 TAPTITE 1.7*3.5 2 X
4-31 AD63-04457A SHEET ABSORB A 1 X
4-32 AD63-04458A SHEET ABSORB B 2 X
4-33 AD63-04592A SHEET ABSORB C 1 X

Samsung NX10 Specifications

General

Megapixel	14.6 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Maximum image resolution	4592 x 3056 pixels
Still image resolution(s)	1472 x 976, 1920 x 1080, 1920 x 1280, 3008 x 1688, 3008 x 2000, 3872 x 2176, 3872 x 2592, 4592 x 2584
Digital zoom	- x
Camera shutter speed	1/4000 - 30 s
Focus	TTL
Focus adjustment	Auto
Auto focusing (AF) modes	Multi Point Auto Focus
ISO sensitivity	100, 200, 400, 800, 1600, 3200, Auto
Video formats supported	H.264, MP4
Maximum video resolution	1280 x 720 pixels
Display diagonal	3 \
Display resolution (numeric)	614000 pixels
USB version	2.0
Product color	Black
Battery type	BP1310
Battery capacity	1300 mAh
Battery life (max)	3.5 h
Battery life (CIPA standard)	400 shots
Bundled software	SAMSUNG Master, SAMSUNG RAW Converter 3.1 Adobe Reader, QuickTime Player 7.6
Operating temperature (T-T)	5 - 85 °C
Maximum operating temperature range (T-T)	0 - 40 °C
Flash modes	fill-in, Red-eye reduction, second curtain synchro
Scene modes	Documents, Night, Portrait, Landscape (scenery)
Camera playback	single image, slide show

Weight and Dimensions

Depth	87 mm
Width	123 mm
Height	39.8 mm
Weight	353 g
