Samsung NX10 Service Manual

Exploded View and Parts List
3-10 This Document can not be used without Samsung's authorization SAMSUNG
Loc. No Parts No.. Description Q ty Available Remark
5-1 AD61-04070A
BASE FINDER 1 X
5-2 AD66-00670A LINK EP 1 X
5-3 AD63-04201A CUSHION FINDER 1 X
5-4 AD61-04255A HOLDER LENS 1 X
5-5 AD67-01396A LENS G1 1 X
5-6 AD64-02676A MASK EVF 1 X
5-7 AD67-01397A LENS G2 1 X
5-8 AD67-01398A LENS G3 1 X
5-9 AD64-02684A MASK LENS 1 X
5-10 AD63-03976A COVER FINDER 1 X
5-11 AD63-04132A T/SHEET EYEPIECE FFC 1 X
5-12 AD64-02660A WINDOW EYEPIECE 1 X
5-13 AD63-04197A T/SHEET FINDER WINDOW A 1 X
5-14 AD63-04196A T/SHEET FINDER WINDOW B 1 X
5-15 6031-001688 WASHER B 1 X
5-16 AD66-00669A GEAR EP 1 X
5-17 6003-001756 SCREW 1 X
5-18 AD73-00332A RUBBER EP RING 1 X
5-19 AD97-18499A ASSY EVF 1 X
5-20 AD97-17732B ASSY-FINDER 1 O

Samsung NX10 Specifications

General

Megapixel	14.6 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Maximum image resolution	4592 x 3056 pixels
Still image resolution(s)	1472 x 976, 1920 x 1080, 1920 x 1280, 3008 x 1688, 3008 x 2000, 3872 x 2176, 3872 x 2592, 4592 x 2584
Digital zoom	- x
Camera shutter speed	1/4000 - 30 s
Focus	TTL
Focus adjustment	Auto
Auto focusing (AF) modes	Multi Point Auto Focus
ISO sensitivity	100, 200, 400, 800, 1600, 3200, Auto
Video formats supported	H.264, MP4
Maximum video resolution	1280 x 720 pixels
Display diagonal	3 \
Display resolution (numeric)	614000 pixels
USB version	2.0
Product color	Black
Battery type	BP1310
Battery capacity	1300 mAh
Battery life (max)	3.5 h
Battery life (CIPA standard)	400 shots
Bundled software	SAMSUNG Master, SAMSUNG RAW Converter 3.1 Adobe Reader, QuickTime Player 7.6
Operating temperature (T-T)	5 - 85 °C
Maximum operating temperature range (T-T)	0 - 40 °C
Flash modes	fill-in, Red-eye reduction, second curtain synchro
Scene modes	Documents, Night, Portrait, Landscape (scenery)
Camera playback	single image, slide show

Weight and Dimensions

Depth	87 mm
Width	123 mm
Height	39.8 mm
Weight	353 g
