Samsung NX10 Service Manual

SAMSUNG This Document can not be used without Samsung’s authorization 3-15
Exploded View and Parts List
Loc. No Parts No.. Description Q ty Available Remark
8-1
AD63-03959A
COVER TOP 1 X BLACK
AD63-03959B COVER TOP 1 X BROWN
8-2 AD97-17742A ASSY-BASE HOT SHOE 1 O
8-3 AD61-04081A PLATE-HOT SHOE 1 O
8-4 AD61-04088A PLATE-HOT SHOE BOTTOM 1 O
8-5 6001-002297 SCREW-MACHINE 2 X
8-6 AD97-17751A STROBO ASSY 1 O
8-7 AD61-04136A BUSH-POP UP A 1 X
8-8 6107-001785 SPRING-TS(POP UP) 1 X
8-9 AD61-04137A BUSH-POP UP B 1 X
8-10 AD66-00689A SHAFT-POP UP 1 X
8-11 6044-001184 RING-E_1 1 X
8-12 6044-001136 RING-E_2 1 X
8-13 AD64-02622A BUTTON-MENU 1 O
8-14 6107-001783 SPRING-CS(MENU) 1 X
8-15 6031-001628 WASHER PLAIN 1 X
8-16 AD64-02621A BUTTON-POP UP 1 O
8-17 AD64-02620A BUTTON-DRIVE 1 O
8-18 AD97-17743A ASSY-HOLDER HOT SHOE FPCB 1 O
8-19 6003-001641 SCREW-TAPTYPE 4 X
8-20 6003-001753 SCREW-TAPTYPE 1 X
8-21 AD61-04078A PLATE-HOT SHOE HOLD 1 X
8-22 6001-001745 SCREW-MACHINE 2 X
8-23 AD66-00671A LEVER POWER 1 X
8-24 6107-001788 SPRING RELEASE 1 X
8-25 AD64-02619A BUTTON RELEASE 1 X
8-26 6031-001628 WASHER PLAIN 1 X
8-27 AD64-01738A KNOB MODE DIAL-CLICK BALL 1 X
8-28 AD61-04087A PLATE-POWER LEVER CLICK 1 O
8-29 AD67-01174A CONTACT-POWER LEVER 1 O
8-30 6003-001297 SCREW-TAPTYPE 2 X
8-31 AD63-04198A T/SHEET-WINDOW AF 1 X
8-32 AD64-02606A WINDOW-AF 1 X
8-33 6107-001784 SPRING-CS(MODE DIAL) 2 X
8-34 AD64-01738A KNOB MODE DIAL -CLICK BALL 2 X

Samsung NX10 Specifications

General

Megapixel	14.6 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Maximum image resolution	4592 x 3056 pixels
Still image resolution(s)	1472 x 976, 1920 x 1080, 1920 x 1280, 3008 x 1688, 3008 x 2000, 3872 x 2176, 3872 x 2592, 4592 x 2584
Digital zoom	- x
Camera shutter speed	1/4000 - 30 s
Focus	TTL
Focus adjustment	Auto
Auto focusing (AF) modes	Multi Point Auto Focus
ISO sensitivity	100, 200, 400, 800, 1600, 3200, Auto
Video formats supported	H.264, MP4
Maximum video resolution	1280 x 720 pixels
Display diagonal	3 \
Display resolution (numeric)	614000 pixels
USB version	2.0
Product color	Black
Battery type	BP1310
Battery capacity	1300 mAh
Battery life (max)	3.5 h
Battery life (CIPA standard)	400 shots
Bundled software	SAMSUNG Master, SAMSUNG RAW Converter 3.1 Adobe Reader, QuickTime Player 7.6
Operating temperature (T-T)	5 - 85 °C
Maximum operating temperature range (T-T)	0 - 40 °C
Flash modes	fill-in, Red-eye reduction, second curtain synchro
Scene modes	Documents, Night, Portrait, Landscape (scenery)
Camera playback	single image, slide show

Weight and Dimensions

Depth	87 mm
Width	123 mm
Height	39.8 mm
Weight	353 g
