setup
50_
setup
Back Light
The Backlight function is dedicated to SV-V DSP (SCP-3XX0) or W-V
DSP (SCP-2XX0) chip, developed by Samsung Techwin, which,
unlike the old models, provides a sharp image of both object and
background against a severe counter-light condition.
Back Light Mode
OFF : Disables the Backlight mode.
WDR : Activates the Wide Dynamic Range mode.
HLC : Activates the High Light Compensation mode.
BLC : Activates a user defi ned backlight compensation mode.
WDR (SCP-3XX0 Only)
When there are both bright and dark areas at the same time, this
mode makes both areas distinctive.
WDR ON
WDR OFF
Limit : Three WDR sensitivity levels are available in 3: Low, Medium , and High.
Note that the higher the sensitivity level, the lower the contrast in the light and dark areas becomes.
Level : Adjusts the screen brightness in WDR mode.
z
-
-
-
-
-
-
Camera Setting
Zoom/Focus
White Balance AUTO
Exposure
Back Light OFF
AGC High
SSNR Medium
SSDR
Day & Night
Others
Æ
Main Menu
Camera Setting
Sequence Setting
P/T Setting
OSD Setting
Alarm Setting
Initialize
Password Setting
Status
WDR Setting
Limit LOW
Level 50
Mode ON
Anti Rolling ON
To Next Page
