39
06. Function setting
Symbol SymbolDescription Description
Converting to the current screen to the next screen
Setting the key lock in the parameter
●
The screen movement and key lock release are available
Converting to the setting screen for corresponding channel
Move to channel (7~12)
Change of parameter in the currently selected channel
Change of every parameter as same [Refer 1]
● When “Function set” is selected from [fig. 3-1 Main screen], it is converted to “Function setting screen.”
● It is the screen for setting the additional function of the product.
06. Function setting
[Fig. 6-1] Function setting screen #1 [Fig. 6-2] Function setting screen #2
[Refer 1]
