Instruction Description
RECORDING CYCLE
Setting the saving period
TIME Saving period adopted to the INTERVAL
RECORD MEDIA
Setting the place to save the recorded graph
MEM Saving into the internal memory
SD Saving into the SD card
BOTH Saving into the internal memory and SD card simultaneously
POWER STOP MODE
Setting the recovery operation in case of blackout
STOP Pause the saving operation
HOT
Saving by creating new file
● The history is saved in recovering after motion for blackout and display the message on the graph
RESTRICT OF MAIN
The keypad for password input is displayed when the main button is pressed in the recording screen in case of setting the main
button restriction. Refer to [Fig. 6-7]
BASIC SCREEN
Set the record screen displayed when entering the 'graph record' screen
TREND Display the trend screen
BAR Display the bar graph screen
DIGIT Display the digital graph screen
PEN USING
Setting the Y/N for the pen (PV graph display) in the corresponding channel of the recording screen
● When the pen is set not for use, it is not displayed and not saved in the graph recording screen
GRAPH SCALE
Setting the upper and lower limit of the scale bar in the recording screen
PEN THICKNESS
Setting of the pen thickness (PV graph display)
● Set line thickness to 1 pixel or 3 pixels
PV DISPLAY METHOD
Setting the PV display type displayed in the scale bar of the recording screen
TAG Display in tag type of the PV display method for scale bar. Refer to [Fig. 6-5]
BAR Display in bar type of the PV display method for scale bar. Refer to [Fig. 6-6]
