[Fig. 14-1] Alarm signal setting screen 1
14. Alarm signal
14-1. Alarm signal setting screen 1
● When the “Alarm signal” is selected in the [Fig. 12-1 System parameter screen], the parameters related in alarm signal can be set.
● The following table is explanation for channel (1~6) and the screen for channel (7~12) is same with channel (1~6).
Instruction Description
Setting the alarm motion
The alarming motion is performed in case of saving
The alarming motion is performed always regardless of save/pause
Parameter Initial value
Channel #n ALARM OPERATION RECORD, ALWAYS
Setting range Unit
ABS A LWAYS
RECORD
ALWAYS
※ #n : 1 ~ 12
ALARM OPERATION
