81
14. Alarm signal
14-2. Alarm signal setting screen 2
● It is the screen to set the alarm for each channel.
● The following table is explanation for channel (1~6) and the screen for channel (7~12) is same with channel (1~6).
● There are 4 channels for alarm signal.
● There are 9 types for alarm signal
Instruction Description
The type of the alarm signal is set.
Alarm type 1
Alarm type 2
Alarm type 3
Alarm type 4
[Fig. 14-2] Alarm signal setting screen 2 #1 [Fig. 14-3] Alarm signal setting screen 2 #2
