9.2 Creating BMP File for USER SCREEN image
▶ Required to use the [Photoshop] to create a BMP file.
☞ The ‘Paint’ in Accessories cannot create a 16BIT BMP image.
▶ BMP File Structure
☞ 16BIT(X1 R5 G5 B5) BMP
▶ Required Pixels
☞ USER SCREEN : 640 X 480 pixels
☞ INITIAL SCREEN : 640 X 480 pixels
☞ DI ERRIR PICTURE : 520 X 422 pixels
▶ Required File Name
☞ USER SCREEN : CS1.BMP, CS2.BMP, CS3.BMP ~ CS14.BMP, CS15.BMP, CS16.BMP(16 in total)
☞ INITIAL SCREEN : INIT.BMP
☞ DI ERROR PICTURE : DI1.BMP, DI2.BMP, DI3.BMP ~ DI14.BMP, DI15.BMP, DI16.BMP(16 in total)
－ File name for each image should be fixed as mentioned above. USER SCREEN, INITIAL SCREEN
and DI ERROR PICTURE cannot be replaced by files with names other than the specified ones
above.
－ When saving your image in [Photoshop] save as BMP.
☞ Name the folder inside the SD CARD as BMP.
※ More information on making a BMP file can be downloaded of SAMWONTECH's website.
[Figure 9-2] USER SCREEN viewer button
