2 Handling overview
▶ This product is programmable controller for temperature and humidity, designed with Touch Screen
interface for user friendly easy access.
2.1 Initial operation flow
▶ Supplying the power after completing installation correctly, loading screen will appear for loading time
then Initial Logo screen will be displayed. The screen will automatically progress to the STOP screen.
☞ It takes around 18 seconds for loading.
▶ Press the
(MAIN) button at the top right hand corner on PROGRAM STOP screen, to move to the
MAIN MENU where the general parameter group located.
▶ Initial Logo screen can be changed as user want. Refer to the [13. INITIAL SETTING] on [Installation
Manual] for how to change initial logo.
Loading screen
Initial Logo screen
MAIN MENU screen PROGRAM STOP screen
To Next Page
