S&C TripSaver II Installation And Operation

20 S&C Instruction Sheet 461-502
Factory Default Settings
All TripSaver II reclosers are shipped with the factory
default settings shown below. These settings will protect
the overhead power line in case an uncongured TripSaver
II recloser is installed. Use the conguration kit and the
S&C TripSaver II® Service Center Conguration Software
to properly congure a TripSaver II recloser before putting
it in use.
NOTICE
Failure to properly configure a TripSaver II recloser
in accordance with applicable codes and standards
can result in slow or no response to a fault level and
miscoordination. Settings should be determined and
approved by qualified persons who are familiar with
the principles of selective coordination and system
protection.
Default TCC Curve Settings
• Initial Trip (1st curve): Microprocessor recloser:
S&C 104 curve; minimum trip current: 100 A;
time multiplier: x1
• Open Interval After Initial Trip: 5 seconds
• Sequence Coordination (disabled by default):
Microprocessor recloser: S&C 133 curve; minimum trip
current: 100 A; time multiplier: 2
• Coordination Reset Time: 120 seconds
• Test 1 (2nd curve): Microprocessor recloser: S&C 104
curve; minimum trip current: 100 A; time multiplier: x1
• Open Interval After Test 1: 5 seconds
• Test 2 (3rd curve): Microprocessor recloser: S&C 133
curve; minimum trip current: 100 A; time multiplier: x2
• Open Interval After Test 2: 5 seconds
• Test 3 (4th curve): Microprocessor recloser: S&C 133
curve; minimum trip current: 100 A; time multiplier: x2
• Sequence Reset Time: 15 seconds
Default NR Curve Settings
• Standard NR: Microprocessor recloser: Denite
time; minimum trip current: 100 A; time: 0 seconds
• Post-Fault Wakeup NR Curve: Microprocessor
recloser: denite time; minimum trip current: 100 A;
time: 0 seconds
• Cold Wakeup NR Curve: Microprocessor recloser:
definite time; minimum trip current: 100 A; time:
0 seconds
Default LCD Screen Settings
• Screen to display when recloser is dropped-open:
Primary Normal screen
• Language: English
• Normal screen: Primary Normal screen
• Number of times the display screen sequence
repeats: 2 times
• Duration of each display screen item: 3 seconds
• Display screen items: Primary Normal screen;
load current; last fault magnitude; number of open
operations; remaining contact wear in %; LCD screen
temperature; software versions
Default Communications Settings
• Communication Mode: Non-Gateway mode
• Side-magnet Radio Enabling Function: Enabled
Default Local Manual Open Settings
• Function: Disabled
Operation
