Chapter 2 – Product Specifications
Revision 2.2 SanDisk SD Card Product Manual
© 2004 SanDisk Corporation 2-1 12/08/04
2 Product Specifications
2.1 Overview
In this section, all values are defined at an ambient temperature and nominal supply voltage
unless otherwise stated.
2.2 System Environmental Specifications
Table 2-1 defines the environmental specifications for the SanDisk SD Card.
Table 2-1 Environmental Specification Summary
Operating -25° C to 85° C Temperature
Non-operating -40° C to 85° C
Operating 25% to 95%, non condensing Humidity
Non-operating 25% to 95%, non condensing
Contact Pads +/- 4kV, Human body model
according to ANSI EOS/ESD-S5.1-
1998
ESD Protection
Non Contact Pad Area +/- 8kV (coupling plane discharge)
+/- 15kV (air discharge)
Human body model per IEC61000-
4-2.
2.3 Reliability and Durability
Table 2-2 Reliability and Durability Specifications
Durability 10,000 mating cycles
Bending 10N
Torque 0.15N.m or ±2.5 deg.
Drop Test 1.5m free fall
UV Light Exposure UV: 254nm, 15Ws/cm2 according to ISO 7816-1
Visual Inspection/Shape and Form No warpage; no mold skin; complete form; no
cavities; surface smoothness ≤ -0.1 mm/cm2 within
contour; no cracks; no pollution (oil, dust, etc.)
Minimum Moving Force of WP Switch 40 gf (ensures that the WP switch will not slide while it
is inserted in the connector).
WP Switch Cycles Minimum 1,000 Cycles @ slide force 0.4N to 5N
