Chapter 2 – Product Specifications
Revision 2.2 SanDisk SD Card Product Manual
© 2004 SanDisk Corporation 2-3 12/08/04
2.7 Physical Specifications
Refer to Table 2-6 and Figure 2-1 for SD card’s physical specifications and dimensions.
Table 2-6 SD Memory Card Physical Specification Summary
Specification SD Card
Weight 2.0 g. maximum
Length 32 mm ± 0.1 mm
Width 24 mm ± 0.1 mm
Thickness 2.1 mm ± 0.15 mm (in substrate area only, 2.25 mm maximum)
Figure 2-1 SD Memory Card Dimensions (Bottom View)
