34
Specifications
Model SHDFSAT12
Tuner
Standard DVB-S/S2
Input Frequency 950~2150MHz
Input Connector F type, female 75 ohm
LNB Supply
14.0V / 19.0V
(maximum.350mA),
short-circuit protected
Digital Signal Input
Level
-20 to -65 dBm
Video
HDMI Output
Resolution 576i / 576p / 720p /
1080i /1080p
SCART Output TV (CVBS/RGB) & VCR (CVBS)
Aspect Ratio 4:3, 16:9 and letter box
Audio
TV & VCR SCART Output Audio Left & Right
Optical S/PDIF Output
Dolby Digital, Dolby Digital +
& PCM
USB Host
2.0 (5V@1A max) for software
upgrade only.
Internet
Connectivity
Ethernet
RJ-45 10/100 Base-T (with
green Link LED & yellow Data
LED)
Power
Requirements
Mains input voltage 100-240V AC~ 50Hz
Power Consumption
Max 13W (LNB with 200mA) &
Standby less than 0.5W
Dimensions
Width, Depth and
Height
281mm x 240mm x 56mm
Features and specifications are subject to change without prior notice.
SHDFSAT12_IB_V2.indd 34 13/06/2013 12:20
