settings in order to facilitate cleaning the grinding body, burrs and the anti-static tab.
• Close the shutter of the bean hopper (2).
• Empty the coffee beans from the grinding body (25), with the "Pulse" button or by
distributing several doses.
• Remove the bean hopper (2).
• Unscrew 2 turns the 3 grinding body closing screws (22) (Fig. D).
• Without touching the indexing lever (23), slightly turn and lift the adjustment nut (24) to
access the inside of the grinding body.
Reassembly:
• Place the upper body (21) back in the lower body (25) making sure to properly align
the parts so that they do not become stuck. Do not force.
• Position the upper body abutting against the locking slots (anticlockwise rotation).
• Tighten the 3 retaining screws (22).
Cleaning the grinding body
Regularly clean the grinding body (25) with a brush (see chapter: "Quick access to the
grinding body").
Cleaning of the anti-static tab
Clean the anti-static tab (34) and if necessary, replace it (34) (see chapter: Quick access
to the grinding body").
.
Cleaning the coffee outlet conduit
Clean the coffee outlet conduit (13) regularly with a brush. Do not insert any aggressive
object (see chapter: "Quick access to the grinding body").
SAFETY
Bean hopper safety
The appliance cannot start if the bean hopper (2) is not correctly positioned on the
appliance.
SERVICING
Before working on the appliance, it is essential to disconnect it from the mains (7).
Spare parts
This machine does not require any particular maintenance. The bearings are lubricated for
life.
If it is necessary to replace wear parts such as burrs, electrical components or other parts,
refer to the parts list (see exploded view at the end of this manual).
When ordering spare parts (for part numbers see the exploded view at the end of this
manual), specify:
➢ the type,
➢ the serial number of the appliance and
➢ the electrical specifications (6)
marked on the bottom of the appliance.
