Access to the inside of the appliance
Before working on the appliance, it is essential to disconnect it from the mains (7).
Opening of the side cover (19): use the 2 keys 67005 (33) provided with the appliance.
• Insert the 2 keys (33) in the kerfs (32) of the Left side cover
• Gently pull the 2 keys to unclip the cover.
Replacing burrs
IMPORTANT! always replace the 2 burrs (27) at the same time.
Use only SANTOS burrs
Refer to the table of the appliance's specifications to order the reference for
the burrs set that corresponds to your appliance.
The 2 burrs are identical and can be mounted on the movable plate (26) (movable
burr) or on the adjustment nut (24) (fixed burr) (fig. E).
1. Close the bean shutter (3) (fig. A).
2. Turn on the appliance, draw several doses to empty the grinding body.
3. Turn off the appliance and disconnect the power cord (7).
4. Remove the bean hopper (2).
5. Loosen the adjustment nut of the burrs (24) one half turn (anticlockwise direction).
6. Unlock and unscrew 2 turns the 3 locking screws (22) of the upper grinding body
(fig. D).
7. Remove the upper portion of the grinding body (21).
8. Unscrew the 3 screws from each burr (fig. E). Note: To lock the rotation of the burr
support plate (26) when unscrewing or screwing the fastening screws of the movable
burr, place a non-aggressive screwdriver between the grinding body and one of the
fins of the plate.
CAUTION! Do not insert the screwdriver into the orifice of the coffee
outlet conduit. This would destroy the anti-static tab and interfere with
the proper functioning of the appliance.
9. Perfectly clean the entire grinding body and in particular the burrs supports.
10. Place each burr on its support, making sure that there is no coffee dust between the
burr and its support.
CAUTION! The slightest small coffee particle placed under the burr can
interfere with the proper operation of the appliance. We recommend
cleaning the grinding body assembly with a compressed air jet or a dry
brush.
CAUTION! do not unscrew the fastening shaft (30) from the burr support
plate (26) in order to avoid damaging the geometry of the whole (fig. E).
11. Once the 2 burrs are replaced, place the upper body (21) back in the lower body (25)
