Sanyo PDG-DHT8000L Service Manual

-162-
KE2-DHT8000L00
PACKING MATERIALS
610 350 7170 CARTON CASE-KE2AL
610 344 8701 SPACER-KT5AL
610 343 9105 CUSHION BTM-KH5AL
610 343 9099 CUSHION TOP-KH5AL
645 099 7266 POLY BAG-1100X0850*NC*R8P
ACCESSORIES
COLOR WHEEL (COLOR)
CW1 610 350 7156 COMPL HOLD CW COLOR-KE2AL
CW2 610 350 7156 COMPL HOLD CW COLOR-KE2AL
OWNER’S MANUAL
910 319 5347 COLOR MANAGE INST-B-MM7A
610 350 9686 SETUP INST MANUAL-KE2AL
610 350 9891 CD-ROM,OWNERS MANUAL-KE2AL
REMOTE CONTROL
645 102 4619 ASSY,REMOCON CXZZ(SYANAI)
610 342 0400 RC-BATTERY LID-CXZL
AC CORD HOLDER
US 610 342 7744 HOLDER AC CODE US-KH5AL
EU/UK 610 342 7751 HOLDER AC CODE EU-LH5AL
! AC CORD
US 945 069 2902 CORD,POWER-3.0MK,US
EU 945 066 7160 CORD,POWER-3.0MK,EU
UK 945 066 7153 CORD,POWER-3.138MK,UK
BRA 645 102 6996 CORD,POWER-2.5MK,BRA
MISCELLANEOUS
945 072 1121 CD-ROM (R.C. MANAGER)
945 073 4855 CABLE,INTERFACE VGA
645 093 1642 CABLE,INTERFACE VGA
652 002 9552 CABLE,INTERFACE VGA
MECHANICAL PARTS
CABINET PARTS
C01 610 335 5092 COMPL,STAND LEG-KC3BL
C02 610 343 6258 BUTTON LNS-KH5AL
C03 610 343 6265 BUTTON CONTROL-KH5AL
C04 610 342 8666 CABINET FRONT-KH5AL
C05 610 350 5541 CABINET TOP-KE2AL
C06 610 342 8680 CABINET TOP COVER-KH5AL
C07 610 350 6791 CABINET BOTTOM-KE2AL
C08 610 342 7799 COVER NON LNS-KH5AL
C09 610 350 5534 COVER BOTTOM-KE2AL
C10 610 343 5633 COVER FILTER-KH5AL
C11 610 343 6807 COVER LNS-KH5AL
C12 610 343 9082 COVER SCREW CAB TOP-KH5AL
C13 610 343 6272 DEC INLAY LED-KH5AL
C14 610 343 6289 DEC INLAY RC FRONT-KH5AL
C15 610 343 6296 DEC INLAY LED AV PNL-KH5AL
C16 610 342 5665 DEC SHEET RC REAR-KH7AL
C17 610 351 4833 DEC AV SHEET-KE2AL
C18 610 344 0484 DEC AC SHEET-KH5AL
C19 610 343 5657 HANDLE A-KH5AL
C20 610 343 5671 HANDLE B-KH5AL
C21 910 283 5855 KNOB-MJ6A
C22 610 345 4160 PANEL COMP A-KH5AL
C23 610 350 6784 PNL AV-KE2AL
C24 610 344 8459 SPACER AC SHEET US-KH5AL
C25 610 346 2325 SPACER COVER BTM-KH5AL
C26 610 344 3942 BADGE SANYO-KH5AL
CHASSIS PARTS
M01 610 350 7811 ASSY,BOX FILTER-KE2AL
M02 610 342 6785 ASSY,HOLDER LNS B-KH5AL
M02-1 945 042 7344 ASSY,MOTOR(ML6A)
M02-2 645 099 7716 UNIT,LENS,SHIFT-X,KH5AL
M02-3 645 099 7723 UNIT,LENS,SHIFT-Y,KH5AL
M03 610 342 9335 COMPL,MOUNTING SHUTTER-KH5AL
M04 610 342 9342 COMPL,MOUNTING DB-KH5AL
M05 610 343 6357 ARM LNS LOCK X-KH5AL
M06 610 343 6364 ARM LNS LOCK Z-KH5AL
M07 610 344 4062 COVER SCREW LNS-KH5AL
M08 610 352 8366 COVER PFC PWB-KE2AL
M09 610 334 3549 GEAR MOTOR-KC3A
M10 610 350 7316 COMPL,MOUNTING PELT-KE2AL
M11* 610 344 3874 HEAT SINK SHEET DMD-KH5AL
M12 610 343 0669 HOLDER FILTER DUCT-KH5AL
M13 610 343 0676 HOLDER FILTER-KH5AL
M14 610 350 6913 HOLDER FILTER BASE-KE2AL
M15 610 343 6333 HOLDER AC BRKT-KH5AL
M16 610 343 6326 HOLDER BALLAST-KH5AL
M17 610 343 6371 HOLDER RC FRONT-KH5AL
M18 610 343 6388 HOLDER CONTROL-KH5AL
M19 610 343 6791 KNOB LNS KH5AL
M20 610 334 4300 MTG HLD SHAFT FIL-KC3A
M21 610 344 4284 SPACER NUT-KH5AL
M22 610 344 0354 SPACER AC BRKT-KH5AL
M23 610 343 9075 SPACER CUSHION DMD-KH5AL
M24 610 346 5173 SPACER CUSHION DMD B-KH5AL
M25 610 343 9204 SPACER KAPTON SHEET KH5AL
M26 610 343 7804 SHIELD DMD-KH5AL
M27 610 343 9020 SPRING SPACER DMD-KH5AL
M28 610 343 9037 SPRING BUTTON LNS-KH5AL
M29 610 343 9044 SPRING LNS LOCK-KH5AL
M30 610 346 1045 SPRING DMD-KH5AL
M31 610 350 6883 OPTICAL LMP COVER-KE2AL
M32 610 350 6876 OPTICAL LMP DUCT BOX-KE2AL
M33 610 350 6906 OPTICAL LMP DUCT A-KE2AL
M34 610 350 6890 OPTICAL LMP DUCT B-KE2AL
M35 610 343 8436 OPTICAL COVER TOP-KH5AL
M36 610 343 8443 OPTICAL COVER BTM-KH5AL
M37 610 345 6881 OPTICAL BASE ROD DUCT-KH5AL
M38 645 099 6955 HOLDER,FAN
M39 610 336 9921 COMP,HOLDER SHAFT FILTER-KC3A
M40 610 350 9860 ASSY,MTG LNS-KH5AL
* Key No. M11 (HEATSINK SHEET) must be replaced with new one when
DMD module or M10 (Peltier Assy) is removed.
SCREWS
S01 312 069 6702 SPECIAL SCREW(BLACK)
S02 411 190 4301 SCR BIN 4X8
S03 411 189 9706 SCR PAN+FLG 3X8
S04 312 069 3909 SPECIAL SCREW V
S05 411 189 6507 BOLT HEX-SCT+SW+W 2.5X5
Key No. Part No. Description
Key No. Part No. Description
Note: Parts order must contain Chassis No., Part No., and Descriptions.
Mechanical Parts List

Sanyo PDG-DHT8000L Specifications

General

Heat dissipation	3286 BTU/h
Projection distance	- m
Projection technology	DLP
Screen size compatibility	- \
Projector native resolution	WUXGA (1920x1200)
Resolution	2073600 pixels
Aspect ratio	16:9
RS-232 ports	1
Dimensions (WxDxH)	398.78 x 523.24 x 241.3 mm
Power requirements	100 - 240V
Focal length range	- mm
Lamp type	UHP
Lamp power	330 W
Light source type	Lamp
Service life of light source	- h
Service life of light source (economic mode)	3000 h
Noise level	35 dB
Dot clock scanning frequency	230 MHz
Built-in speaker(s)	No
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (standby)	- W
Power consumption (typical)	963 W
Display diagonal	0.95 \
Placement	Ceiling

Weight and Dimensions

Weight	19595.19 g
