Sanyo PLC-SU50 Service Manual

-11-
10 G_GAMMA_SHIFT 512/512/512/512 0 ~ 1023
11 R_GAMMA_SHIFT 512/512/512/512 0 ~ 1023
12 B_GAMMA_SHIFT 512/512/512/512 0 ~ 1023
13 TATEMURA_VAL_R0,G0,B0 4 0 ~ 255
14 TATEMURA_VAL_R1,G1,B1 2 0 ~ 255
15 TATEMURA_VAL_R2,G2,B2 1 0 ~ 255
16 TATEMURA_VAL_R3,G3,B3 255 0 ~ 255
17 TATEMURA_VAL_R4,G4,B4 254 0 ~ 255
18 BLOCK_GHOST_R 8 0 ~ 255
19 BLOCK_GHOST_G 8 0 ~ 255
20 BLOCK_GHOST_B 8 0 ~ 255
21
22
23
24
25
26
27
28
29
30 R_MID2 430/398 0 ~ 1023 SVGA/XGA
31 R_MID1 574/544 0 ~ 1023 SVGA/XGA
32 R_MAX 710/690 0 ~ 1023 SVGA/XGA
33 G_MID2 430/398 0 ~ 1023 SVGA/XGA
34 G_MID1 574/544 0 ~ 1023 SVGA/XGA
35 G_MAX 710/690 0 ~ 1023 SVGA/XGA
36 B_MID2 430/398 0 ~ 1023 SVGA/XGA
37 B_MID1 574/544 0 ~ 1023 SVGA/XGA
38 B_MAX 710/690 0 ~ 1023 SVGA/XGA
39 Real/Cinema G_GAMMA_SHIFT
40 Real/Cinema R_GAMMA_SHIFT
41 Real/Cinema B_GAMMA_SHIFT
Group: 10 panel Drive L3E06100
0 G_V1 (DAC) 147 0 ~ 255 * Link with V2
1 R_V1 (DAC) 147 0 ~ 255
2 B_V1 (DAC) 147 0 ~ 255
3 REF_G (DAC) 195 0 ~ 255 ✻ Black Reference Adjustment [G]
4 REF_R (DAC) 195 0 ~ 255 ✻ Black Reference Adjustment [R]
5REF_B (DAC) 195 0 ~ 255 ✻ Black Reference Adjustment [B]
6 G_V2 (DAC) 168 0 ~ 255 * Link with V1
7 R_V2 (DAC) 168 0 ~ 255
8 G_V2 (DAC) 168 0 ~ 255
9 G_LCCOM (L3E6100) 180 0 ~ 255 ✻ Common Center Adjustment [G]
10 R_LCCOM (L3E6100) 180 0 ~ 255 ✻ Common Center Adjustment [R]
11 B_LCCOM (L3E6100) 180 0 ~ 255 ✻ Common Center Adjustment [B]
12 NRS_H G (L3E07070) 255 0 ~ 255 *Link with NRS_H B, R
13 NRS_H R (L3E07070) 255 0 ~ 255 *Link with NRS_L G
14 NRS_H B (L3E07070) 255 0 ~ 255 *Link with NRS_L G
15 NRS_L G (L3E07070) 0 0 ~ 255 *Link with NRS_H B, R
16 NRS_L R (L3E07070) 0 0 ~ 255 *Link with NRS_H G
17 NRS_L B (L3E07070) 0 0 ~ 255 *Link with NRS_H G
Group: 11 Gamma
0 Standard GAMMA 0 0/0 0 ~ 1023
1 Standard GAMMA 1 100/66 0 ~ 1023 PC,DVI Standard / AV Standard
2 Standard GAMMA 2 180/132 0 ~ 1023 Read Only
3 Standard GAMMA 3 308/256 0 ~ 1023
4 Standard GAMMA 4 442/454 0 ~ 1023
5 Standard GAMMA 5 552/544 0 ~ 1023
6 Standard GAMMA 6 647/634 0 ~ 1023
7 Standard GAMMA 7 703/689 0 ~ 1023
8 Standard GAMMA 8 743/729 0 ~ 1023
9 Standard GAMMA 9 776/764 0 ~ 1023
10 Standard GAMMA 10 807/795 0 ~ 1023
11 Standard GAMMA 11 840/822 0 ~ 1023
12 Standard GAMMA 12 874/854 0 ~ 1023
13 Standard GAMMA 13 902/880 0 ~ 1023
14 Standard GAMMA 14 948/905 0 ~ 1023
15 Standard GAMMA 15 1023/935 0 ~ 1023
16 Real/Cinema GAMMA 0 512/512 0 ~ 1023
17 Real/Cinema GAMMA 1 562/551 0 ~ 1023 PC,DVI Real / AV Cinema(Difference from Standard)
18 Real/Cinema GAMMA 2 602/590 0 ~ 1023
19 Real/Cinema GAMMA 3 630/620 0 ~ 1023
20 Real/Cinema GAMMA 4 594/564 0 ~ 1023
21 Real/Cinema GAMMA 5 560/538 0 ~ 1023
22 Real/Cinema GAMMA 6 529/522 0 ~ 1023
23 Real/Cinema GAMMA 7 513/509 0 ~ 1023
24 Real/Cinema GAMMA 8 506/505 0 ~ 1023
25 Real/Cinema GAMMA 9 505/500 0 ~ 1023
26 Real/Cinema GAMMA 10 501/497 0 ~ 1023
27 Real/Cinema GAMMA 11 497/502 0 ~ 1023
28 Real/Cinema GAMMA 12 498/505 0 ~ 1023
29 Real/Cinema GAMMA 13 490/503 0 ~ 1023
No. Adjustment Item Initial Value Range Input source / Description
Electrical Adjustments
