Sanyo PLC-SU50 Service Manual

PH3-SL2000, PG3-XL2000
Electrical Parts List
-26-
R7018 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R7021 401 105 0702 MT-GLAZE 100K JA 1/16W
R7051 401 190 1707 MT-GLAZE 0.000 ZA 1W
R7056 401 105 2805 MT-GLAZE 2.2K JA 1/16W
R7057 401 105 0504 MT-GLAZE 1K JA 1/16W
R7071 401 105 0603 MT-GLAZE 10K JA 1/16W
R7072 401 105 4106 MT-GLAZE 3.3K JA 1/16W
R7073 401 105 6605 MT-GLAZE 6.8K JA 1/16W
COIL
L3071 645 059 2409 FILTER,EMI 35PF
L3072 645 059 2409 FILTER,EMI 35PF
DIODE
D3051 407 209 1201 ZD UDZS-TE-176.2B
407 179 0501 ZENER DIODE UDZ6.2B-TE-17
D3052 407 209 1201 ZD UDZS-TE-176.2B
407 179 0501 ZENER DIODE UDZ6.2B-TE-17
D3053 407 209 1201 ZD UDZS-TE-176.2B
407 179 0501 ZENER DIODE UDZ6.2B-TE-17
D3071 407 221 7106 ZENER DIODE UDZS-TE-1712B
407 187 8209 ZENER DIODE UDZ12B-TE-17
D3072 407 221 7106 ZENER DIODE UDZS-TE-1712B
407 187 8209 ZENER DIODE UDZ12B-TE-17
D7031 407 149 0807 DIODE 1SS355-TE-17
D7052 407 190 4106 DIODE SFPL-52V
D7053 407 190 4106 DIODE SFPL-52V
MISCELLANEOUS
K10E 645 053 7967 SOCKET,DVI 29P
SW7011 645 036 1074 SWITCH,PUSH
(PH3-SL2000)
610 310 3136 ASSY,PWB,POWER MA7A
(PG3-XL2000)
610 310 3167 ASSY,PWB,POWER MT3A
There is no defferential parts on the power board.
TRANSISTOR
Q611 405 140 3704 TR 2SK2698
Q621 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q622 405 134 5905 TR 2SA1037AK-T146-R
405 147 2205 TR 2SA1037AK-S-T146
405 002 0308 TR 2SA1037K T146 R
405 002 0407 TR 2SA1037K T146 S
405 002 6706 TR 2SA1179-M6-TB
405 002 6904 TR 2SA1179-M7-TB
405 163 1503 TR 2SA1179N-M6-TB
405 163 2708 TR 2SA1179N-M7-TB
405 173 9605 TR 2SA1235A1E
405 173 9704 TR 2SA1235A1F
Q642 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q651 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q661 405 047 9007 TR 2SB1204-S-TL
405 047 9106 TR 2SB1204-T-TL
Q662 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
INTEGRATED CIRCUIT
IC621 409 523 1400 IC FA5502M
IC631 409 558 4209 IC STR-Z2156A
IC651 409 344 6509 IC UPC1093T-E1
CAPACITOR
!C601 404 081 4702 MT-POLYEST 0.22U M 275V
!C602 404 081 4702 MT-POLYEST 0.22U M 275V
C611 403 222 1303 CERAMIC 1000P K 1K
C612 403 222 1303 CERAMIC 1000P K 1K
C613 403 372 0003 MT-POLYEST 2.2U K 400V
C614 403 372 0003 MT-POLYEST 2.2U K 400V
C615 404 095 1100 ELECT 180U M 450V
404 095 1209 ELECT 180U M 450V
C616 403 371 8604 MT-POLYEST 0.1U K 450V
C62A 403 157 3304 CERAMIC 68P J 50V
C62B 403 157 6602 CERAMIC 470P K 50V
C62C 403 325 6304 CERAMIC 0.22U K 10V
C62D 403 164 0204 CERAMIC 0.1U Z 25V
C62E 403 164 0204 CERAMIC 0.1U Z 25V
C62I 403 149 9208 CERAMIC 0.01U Z 50V
C62J 403 169 2807 CERAMIC 330P J 50V
C62K 403 323 3602 CERAMIC 0.047U K 50V
C62M 403 164 0204 CERAMIC 0.1U Z 25V
C62R 403 175 3706 ELECT 4.7U M 50V
C62T 403 164 0204 CERAMIC 0.1U Z 25V
C631 403 192 4809 TA-SOLID 2.2U M 35V
C633 403 113 3805 CERAMIC 1000P K 50V
C634 403 247 3306 CERAMIC 330P K 2K
C635 403 167 8603 CERAMIC 220P K 2K
C636 403 070 2606 CERAMIC 0.1U Z 50V
C637 403 157 6800 CERAMIC 680P K 50V
C638 403 208 1402 TA-SOLID 1U M 25V
C639 403 356 1804 ELECT 220U M 35V
C640 403 164 0204 CERAMIC 0.1U Z 25V
C641 403 352 8203 CERAMIC 0.47U Z 16V
C642 403 083 4307 POLYPRO 0.022U J 400V
C643 403 256 2406 CERAMIC 0.22U Z 50V
C644 403 164 0204 CERAMIC 0.1U Z 25V
C651 403 369 2409 ELECT 2700U M 25V
C652 403 350 5303 ELECT 3900U M 10V
C653 403 331 0303 ELECT 470U M 16V
C654 403 164 0204 CERAMIC 0.1U Z 25V
C655 403 164 0204 CERAMIC 0.1U Z 25V
C656 403 345 9606 CERAMIC 0.47U K 10V
POWER BOARD
Key No. Part No. Description Key No. Part No. Description
