Sanyo PLC-SU50 Service Manual

PH3-SL2000, PG3-XL2000
-25-
Electrical Parts List
407 187 8209 ZENER DIODE UDZ12B-TE-17
D2051 407 221 7106 ZENER DIODE UDZS-TE-1712B
407 187 8209 ZENER DIODE UDZ12B-TE-17
D2052 407 221 7106 ZENER DIODE UDZS-TE-1712B
407 187 8209 ZENER DIODE UDZ12B-TE-17
D2053 407 221 7106 ZENER DIODE UDZS-TE-1712B
407 187 8209 ZENER DIODE UDZ12B-TE-17
D2054 407 221 7106 ZENER DIODE UDZS-TE-1712B
407 187 8209 ZENER DIODE UDZ12B-TE-17
D221 407 149 0807 DIODE 1SS355-TE-17
D5001 401 037 5608 MT-GLAZE 10K JA 1/10W
D5031 407 149 0807 DIODE 1SS355-TE-17
D5036 407 149 0807 DIODE 1SS355-TE-17
MISCELLANEOUS
K10A 645 009 8093 SOCKET,D-SUB 15P
K10B 645 000 2571 JACK,PHONE D8.0
K10C 645 048 6739 SOCKET,DIN 8P
K10D 645 028 0382 SOCKET,USB 4P
K20A 645 038 4462 JACK,RCA-3
K20B 610 010 8295 SOCKET,DIN 4P
K20D 645 017 1680 JACK,PHONE D3.6
SW1061 645 042 8104 SWITCH,PUSH 1P-1TX1
610 306 7278 ASSY,PWB,DVI MA7A
TRANSISTOR
Q3071 405 134 5905 TR 2SA1037AK-T146-R
405 147 2205 TR 2SA1037AK-S-T146
405 002 0308 TR 2SA1037K T146 R
405 002 0407 TR 2SA1037K T146 S
405 002 6706 TR 2SA1179-M6-TB
405 002 6904 TR 2SA1179-M7-TB
405 163 1503 TR 2SA1179N-M6-TB
405 163 2708 TR 2SA1179N-M7-TB
405 173 9605 TR 2SA1235A1E
405 173 9704 TR 2SA1235A1F
Q3072 405 134 5905 TR 2SA1037AK-T146-R
405 147 2205 TR 2SA1037AK-S-T146
405 002 0308 TR 2SA1037K T146 R
405 002 0407 TR 2SA1037K T146 S
405 002 6706 TR 2SA1179-M6-TB
405 002 6904 TR 2SA1179-M7-TB
405 163 1503 TR 2SA1179N-M6-TB
405 163 2708 TR 2SA1179N-M7-TB
405 173 9605 TR 2SA1235A1E
405 173 9704 TR 2SA1235A1F
Q7011 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
INTEGRATED CIRCUIT
IC3061 409 536 5501 IC AD8074ARU
IC7021 409 428 8405 IC TC7WT125FU-TE12L
IC7031 409 334 0104 IC TC7W125FU
IC7051 409 530 9109 IC PQ070XH02ZP
IC7071 409 334 0104 IC TC7W125FU
CAPACITOR
C1086 403 164 0204 CERAMIC 0.1U Z 25V
C3061 403 304 2105 ELECT 47U M 6.3V
C3062 403 164 0204 CERAMIC 0.1U Z 25V
C3063 403 304 2105 ELECT 47U M 6.3V
C3064 403 164 0204 CERAMIC 0.1U Z 25V
C3066 403 164 0204 CERAMIC 0.1U Z 25V
C3071 403 164 0204 CERAMIC 0.1U Z 25V
C3072 403 164 0204 CERAMIC 0.1U Z 25V
C7001 403 304 1801 ELECT 100U M 6.3V
403 373 7704 ELECT 100U M 6.3V
C7002 403 164 0204 CERAMIC 0.1U Z 25V
C7003 403 341 3905 POS-SOLID 100U M 6.3V
C7004 403 164 0204 CERAMIC 0.1U Z 25V
C7011 403 164 0204 CERAMIC 0.1U Z 25V
C7021 403 164 0204 CERAMIC 0.1U Z 25V
C7031 403 164 0204 CERAMIC 0.1U Z 25V
C7051 403 304 3300 ELECT 47U M 16V
C7052 403 164 0204 CERAMIC 0.1U Z 25V
C7053 403 341 3905 POS-SOLID 100U M 6.3V
C7054 403 164 0204 CERAMIC 0.1U Z 25V
C7071 403 164 0204 CERAMIC 0.1U Z 25V
RESISTOR
R1086 401 105 2805 MT-GLAZE 2.2K JA 1/16W
R1088 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1091 401 105 5202 MT-GLAZE 470 JA 1/16W
R1092 401 105 5202 MT-GLAZE 470 JA 1/16W
R1093 401 105 5202 MT-GLAZE 470 JA 1/16W
R1094 401 105 5202 MT-GLAZE 470 JA 1/16W
R1095 401 105 5202 MT-GLAZE 470 JA 1/16W
R1096 401 105 5202 MT-GLAZE 470 JA 1/16W
R1097 401 105 5202 MT-GLAZE 470 JA 1/16W
R1098 401 105 5202 MT-GLAZE 470 JA 1/16W
R3051 401 113 4402 MT-GLAZE 75 JA 1/16W
R3052 401 113 4402 MT-GLAZE 75 JA 1/16W
R3053 401 113 4402 MT-GLAZE 75 JA 1/16W
R3054 401 113 4402 MT-GLAZE 75 JA 1/16W
R3055 401 113 4402 MT-GLAZE 75 JA 1/16W
R3056 401 113 4402 MT-GLAZE 75 JA 1/16W
R3057 401 113 4402 MT-GLAZE 75 JA 1/16W
R3058 401 113 4402 MT-GLAZE 75 JA 1/16W
R3059 401 113 4402 MT-GLAZE 75 JA 1/16W
R3060 401 113 4402 MT-GLAZE 75 JA 1/16W
R3061 401 113 4402 MT-GLAZE 75 JA 1/16W
R3062 401 113 4402 MT-GLAZE 75 JA 1/16W
R3063 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R3064 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R3065 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R3066 401 105 0405 MT-GLAZE 100 JA 1/16W
R3067 401 105 0405 MT-GLAZE 100 JA 1/16W
R3068 401 105 0405 MT-GLAZE 100 JA 1/16W
R3069 401 105 3307 MT-GLAZE 2.7K JA 1/16W
R3070 401 105 3307 MT-GLAZE 2.7K JA 1/16W
R3071 401 105 0405 MT-GLAZE 100 JA 1/16W
R3072 401 105 2904 MT-GLAZE 22K JA 1/16W
R3073 401 105 0306 MT-GLAZE 10 JA 1/16W
R3074 401 105 0405 MT-GLAZE 100 JA 1/16W
R3075 401 105 0603 MT-GLAZE 10K JA 1/16W
R3076 401 105 0306 MT-GLAZE 10 JA 1/16W
R3077 401 105 3307 MT-GLAZE 2.7K JA 1/16W
R3078 401 105 3307 MT-GLAZE 2.7K JA 1/16W
R3079 401 105 0306 MT-GLAZE 10 JA 1/16W
R3081 401 105 3307 MT-GLAZE 2.7K JA 1/16W
R3082 401 105 3307 MT-GLAZE 2.7K JA 1/16W
R7011 401 105 0603 MT-GLAZE 10K JA 1/16W
R7012 401 105 0603 MT-GLAZE 10K JA 1/16W
R7013 401 105 0603 MT-GLAZE 10K JA 1/16W
R7014 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
DVI BOARD
Key No. Part No. Description Key No. Part No. Description
