Page #12 background imageLoading...
Page #12 background image
-12-
30 Real/Cinema GAMMA 14 469/497 0 ~ 1023
31 Real/Cinema GAMMA 15 424/497 0 ~ 1023
Group 100 H8 Option
0 Lamp Time Monitor 0~8738 Read Only
1 RS232C Baudrate 0 ~ 1 0: 19200bps1: 9600bps
2
3 Cooling Time 3 1 ~ 15 Cooling time1:30 sec.3:90 sec.15:450 sec.
4Hi-Land SW 0 0 ~ 3 0: Normal Mode1~3: High-Land Mode 1-3
5
6 Lamp Total Time 0~65535 Read only
7 Lamp Dim level (Eco) 0 ~ 15
8
9 Reset SW 0 ~ 10 Resets User Setting data when this value is set to 10
10 Color Shading SW 0 ~ 1 0:Color Compensation Off, 1:Color Compensation On
11 RC Enable/Disable 0 0 ~ 3 0:Enable 1:Disable
12 Lamp Dim Level 10 0 ~ 15
13 Lamp Warning Time 0~65535
14
15 Video Mute Forced Off 0 ~ 1 0:VideoMuteOn(Normal) 1:Video Mute Forced Off
16 Safety FAN Control Fix SW 0 ~ 5 0:Normal 1:Normal Min2:Normal Max3:Eco Min4:Eco Max
17 HDCP Option 0 0 ~ 3 0: XGA 1; other than XGA
18 HDCP Reset 0 0 ~ 10
19
Group: 101PW Option
0 Shootout Mode 0 0 ~ 1 1: Shoot Out Mode Enable0: Disable
1V-Sync SW 0 0 ~ 1 0: No Sync 1: Sync with Vertical sync
2 NOBRAND 0 0 ~ 1 0:Normal1:NOBRAND
3
4 HDCP OverScan Rate 0 0 ~ 5
Group: 110 Dimmer Processing
0DIMMER_CTRL_LEVEL1 7 0~255 Dimmer Brightness Level1 Data: Dimmer Level1 when less than this value.
1DIMMER_CTRL_LEVEL2 14 0~255 Dimmer Brightness Level2 Data: Dimmer Level2 when less than this value.
2DIMMER_CTRL_LEVEL3 21 0~255 Dimmer Brightness Level3 Data: Dimmer Level3 when less than this value.
3DIMMER_CTRL_LEVEL4 28 0~255 Dimmer Brightness Level4 Data: Dimmer Level4 when less than this value.
4DIMMER_CTRL_LEVEL5 35 0~255 Dimmer Brightness Level5 Data: Dimmer Level5 when less than this value.
5DIMMER_CTRL_LEVEL6 42 0~255 Dimmer Brightness Level6 Data: Dimmer Level6 when less than this value.
6DIMMER_CTRL_LEVEL7 49 0~255 Dimmer Brightness Level7 Data: Dimmer Level7 when less than this value.
7DIMMER_CTRL_LEVEL8 56 0~255 Dimmer Brightness Level8 Data: Dimmer Level8 when less than this value.
8DIMMER_CTRL_LEVEL9 63 0~255 Dimmer Brightness Level9 Data: Dimmer Level9 when less than this value.
9DIMMER_CTRL_LEVEL10 70 0~255 Dimmer Brightness Level10 Data: Dimmer Level10 when less than this value.
10 DIMMER_CTRL_LEVEL11 77 0~255 Dimmer Brightness Level11 Data: Dimmer Level11 when less than this value.
11 DIMMER_CTRL_LEVEL12 84 0~255 Dimmer Brightness Level12 Data: Dimmer Level12 when less than this value.
12 DIMMER_CTRL_LEVEL13 91 0~255 Dimmer Brightness Level13 Data: Dimmer Level13 when less than this value.
13 DIMMER_CTRL_LEVEL14 98 0~255 Dimmer Brightness Level14 Data: Dimmer Level14 when less than this value.
14 DIMMER_CTRL_LEVEL15 105 0~255 Dimmer Brightness Level15 Data: Dimmer Level15 when less than this value.
15 DIMMER_AVERAGE_POINT 4 1 ~ 16 Average count for Dimmer Brightness Data
16 DIMMER_AVERAGE_DATA - 0 ~ 255 Average Value for Dimmer Brightness Data * Read Only(8 bit)
17 DIMMER_LEVEL_AUTO - 0 ~ 15 Dimmer Level effective in auto-dimmer mode. 0 fixed other than auto mode (Read Only)
18 DIMMER_LEVEL_NONAUTO - 0 ~ 15 Dimmer Level effective other than auto-dimmer mode
Group: 111 Fan Control
0FAN_TEMP_A_WARNING 72/74 30 ~ 100 Temperature A to judge the abnormal temperature, for surrounding temperature SVGA/XGA
1FAN_TEMP_B_WARNING 55/58 30 ~ 100 Temperature B to judge the abnormal temperature, for Panels SVGA/XGA
2FAN_TEMP_C_WARNING 71/73 30 ~ 100 Temperature C to judge the abnormal temperature, for Lamp SVGA/XGA
3FAN_TEMP_B-A_WARNING 100 0 ~ 100 Temperature B-A to judge the abnormal temperature, for detecting clogged filter
4FAN_TEMP_C-A_WARNING 100 0 ~ 100 Temperature C-A to judge the abnormal temperature, for detecting clogged filter
5FAN_CONTROL_SW 1 0 or 1 0: Auto Fan Control 1:Manual Control
6FAN_1_SPEED_CTRL 135 0 ~ 255 Manual Adjustment Mode when FAN_CONTROL_SW=1
7FAN_2_SPEED_CTRL 135 0 ~ 255
8
9FAN_1_SPEED_MONI - 0 ~ 255 Fan Speed Monitor when FAN_CONTROL_SW=0, Read Only
10 FAN_2_SPEED_MONI - 0 ~ 255
11
12 FAN_TEMP_A_MONI - - Read Only
13 FAN_TEMP_B_MONI - -
14 FAN_TEMP_C_MONI - -
15
16 TEMP_UPWARNING_TIME 0 0 ~ 5 +15 degrees is added to Abnormal Temperature Value during x min after power on.
17 NOR_TEMP_FAN1_MIN 41/48 Control Start Temperature for FAN1 at Normal Mode SVGA/XGA
18 NOR_TEMP_FAN1_MAX 48/54 Control End Temperature for FAN1 at Normal Mode SVGA/XGA
19 NOR_TEMP_FAN2_MIN 41/48 0~255 Control Start Temperature for FAN2 at Normal Mode SVGA/XGA
20 NOR_TEMP_FAN2_MAX 48/54 Control End Temperature for FAN2 at Normal Mode SVGA/XGA
21
22
23 NOR_VALU_FAN1_MIN 80/80 Minimum Control Value for FAN1 at Normal Mode (0: Fan Voltage 0V, 255: Fan Voltage 25.5V)
24 NOR_VALU_FAN1_MAX 134/135 Maximum Control Value for FAN1 at Normal Mode
25 NOR_VALU_FAN2_MIN 95/100 0~255 Minimum Control Value for FAN2 at Normal Mode
26 NOR_VALU_FAN2_MAX 135/135 Maximum Control Value for FAN2 at Normal Mode
27
28
29 ECO_TEMP_FAN1_MIN 41/47 Control Start Temperature for FAN1 at Eco Mode SVGA/XGA
No. Adjustment Item Initial Value Range Input source / Description
Electrical Adjustments
