Sanyo PLC-SU50 Service Manual

-13-
30 ECO_TEMP_FAN1_MAX 48/84 Control End Temperature for for FAN1 at Eco Mode SVGA/XGA
31 ECOTEMP_FAN2_MIN 41/47 0~255 Control Start Temperature for FAN2 at Eco Mode SVGA/XGA
32 ECO_TEMP_FAN2_MAX 48/54 Control End Temperature for for FAN2 at Eco Mode SVGA/XGA
33
34
35 ECO_VALU_FAN1_MIN 70/70 Minimum Control Value for FAN1 at Eco Mode
36 ECO_VALU_FAN1_MAX 135/135 Maximum Control Value for FAN1 at Eco Mode
37 ECO_VALU_FAN2_MIN 85/85 0~255 Minimum Control Value for FAN2 at Eco Mode
38 ECO_VALU_FAN2_MAX 130/130 Maximum Control Value for FAN2 at Eco Mode
39
40
41 HINOR_TEMP_FAN1_MIN 41/48 Control Start Temperature for FAN1 at Highland Normal Mode
42 HINOR_TEMP_FAN1_MAX 48/54 Control End Temperature for FAN1 at Highland Normal Mode
43 HINOR_TEMP_FAN2_MIN 41/48 0~255 Control Start Temperature for FAN2 at Highland Normal Mode
44 HINOR_TEMP_FAN2_MAX 48/54 Control End Temperature for FAN2 at Highland Normal Mode
45
46
47 HINOR_VALU_FAN1_MIN 80/80 Minimum Control Value for FAN1 at Highland Normal Mode (0: Fan Voltage 0V, 255: Fan Voltage 25.5V)
48 HINOR_VALU_FAN1_MAX 135/135 Maximum Control Value for FAN1 at Highland Normal Mode
49 HINOR_VALU_FAN2_MIN 95/100 0~255 Minimum Control Value for FAN2 at Highland Normal Mode
50 HINOR_VALU_FAN2_MAX 135/135 Maximum Control Value for FAN2 at Highland Normal Mode
51
52
53 HIECO_TEMP_FAN1_MIN 41/47 Control Start Temperature for FAN1 at Highland Eco Mode
54 HIECO_TEMP_FAN1_MAX 48/54 Control End Temperature for FAN1 at Highland Eco Mode
55 HIECOTEMP_FAN2_MIN 41/47 0~255 Control Start Temperature for FAN2 at Highland Eco Mode
56 HIECO_TEMP_FAN2_MAX 48/54 Control End Temperature for FAN2 at Highland Eco Mode
57
58
59 HIECO_VALU_FAN1_MIN 70/70 Minimum Control Value for FAN1 at Highland Eco Mode (0: Fan Voltage 0V, 255: Fan Voltage 25.5V)
60 HIECO_VALU_FAN1_MAX 135/135 Maximum Control Value for FAN1 at Highland Eco Mode
61 HIECO_VALU_FAN2_MIN 85/85 0~255 Minimum Control Value for FAN2 at Highland Eco Mode
62 HIECO_VALU_FAN2_MAX 130/130 Maximum Control Value for FAN2 at Highland Eco Mode
63
64
65 CLNOR_TEMP_FAN1_MIN 41/48 Control Start Temperature for FAN1 at Ceiling Normal Mode
66 ClNOR_TEMP_FAN1_MAX 48/54 Control End Temperature for FAN1 at Ceiling Normal Mode
67 CLNOR_TEMP_FAN2_MIN 41/48 0~255 Control Start Temperature for FAN2 at Ceiling Normal Mode
68 CLNOR_TEMP_FAN2_MAX 48/41 Control End Temperature for FAN2 at Ceiling Normal Mode
69
70
71 CLNOR_VALU_FAN1_MIN 80/80 Minimum Control Value for FAN1 at Ceiling Normal Mode (0: Fan Voltage 0V, 255: Fan Voltage 25.5V)
72 CLNOR_VALU_FAN1_MAX 135/135 Maximum Control Value for FAN1 at Ceiling Normal Mode
73 CLNOR_VALU_FAN2_MIN 95/100 0~255 Minimum Control Value for FAN2 at Ceiling Normal Mode
74 CLNOR_VALU_FAN2_MAX 135/135 Maximum Control Value for FAN2 at Ceiling Normal Mode
75
76
77 CLECO_TEMP_FAN1_MIN 41/47 Control Start Temperature for FAN1 at Ceiling Eco Mode
78 CLECO_TEMP_FAN1_MAX 48/54 Control End Temperature for FAN1 at Ceiling Eco Mode
79 CLECOTEMP_FAN2_MIN 41/47 0~255 Control Start Temperature for FAN2 at Ceiling Eco Mode
80 CLECO_TEMP_FAN2_MAX 48/54 Control End Temperature for FAN2 at Ceiling Eco Mode
81
82
83 CLECO_VALU_FAN1_MIN 70/70 Minimum Control Value for FAN1 at Ceiling Eco Mode (0: Fan Voltage 0V, 255: Fan Voltage 25.5V)
84 CLECO_VALU_FAN1_MAX 135/135 Maximum Control Value for FAN1 at Ceiling Eco Mode
85 CLECO_VALU_FAN2_MIN 85/85 0~255 Minimum Control Value for FAN2 at Ceiling Eco Mode
86 CLECO_VALU_FAN2_MAX 130/130 Maximum Control Value for FAN2 at Ceiling Eco Mode
87
88
89 FAN1_ADJUST_VOLT_MIN 1 DAC Adjustment Value at minimum driving voltage for FAN1 ✻ Fan Control Adjustment
90 FAN1_ADJUST_VOLT_MAX 230 DAC Adjustment Value at maximum driving voltage for FAN1 ✻ Fan Control Adjustment
91 FAN2_ADJUST_VOLT_MIN 1 0~255 DAC Adjustment Value at minimum driving voltage for FAN2 ✻ Fan Control Adjustment
92 FAN2_ADJUST_VOLT_MAX 230 DAC Adjustment Value at maximum driving voltage for FAN2 ✻ Fan Control Adjustment
93
94
Group: 112 PC Real/ AV Cinema
0 PC Real Contrast 32 0 ~ 63
1 PC Real Brightness 32 0 ~ 63
2 PC Real Red 34 0 ~ 63
3 PC Real Green 32 0 ~ 63
4PC Real Blue 31 0 ~ 63
5 PC Real Gamma 8 0 ~ 15
6AV Cinema Contrast 32 0 ~ 63
7AV Cinema Brightness 32 0 ~ 63
8AV Cinema Color 32 0 ~ 63
9AV Cinema Tint 32 0 ~ 63
10 AV Cinema Red 32 0 ~ 63
11 AV Cinema Green 30 0 ~ 63
12 AV Cinema Blue 29 0 ~ 63
13 AV Cinema Sharpness 8 0 ~ 31
14 AV Cinema Gamma 8 0 ~ 15
15 AV Cinema N.R. 1 0 ~ 2
16 AV Cinema PROGRESSIVE 1 0 or 1
No. Adjustment Item Initial Value Range Input source / Description
Electrical Adjustments
