Sanyo PLC-SU50 Service Manual

-14-
Group: 300 I/P
0 L1 LWDIFFTH 10 0 ~ 255 L1 For motion movie
1 L1 HIDIFFTH 48 0 ~ 255
2 L1 HIMOTHR 1 0 ~ 16
3 L1 LWMOTHR 1 0 ~ 16
4 L2 LWDIFFTH 32 0 ~ 255 L2 Still picture
5 L2 HIDIFFTH 48 0 ~ 255
6 L2 HIMOTHR 6 0 ~ 16
7 L2 LWMOTHR 6 0 ~ 16
Group: 301 Color Gain
0AV Color 32 0 ~ 63 Color[0-63] on AV menu
1 Color Space Converter 48[0-63] 0 ~ 4096 PW463 Extended Input Port CSC
2 TB1274AF C Out 21/29/20/28 0 ~ 63 Video S-VideoOther/SECAM,BW/YCbCr/Scart[0-63]
3 TB1274AF Sub Color 8/8/8/8 0 ~ 16 Video S-Video Other/SECAM,BW/ YCbCr/Scart
Group: 500 NTSC Gakaku (Composite/Svideo) at I/P OFF
0 NTSC TOTAL DOTS 1311 0 ~ 4096
1 NTSC DISP DOTS 1025 0 ~ 4096
2 NTSC H BACK PORCTH 234 0 ~ 4096
3 NTSC V BACK PORCTH 48 0 ~ 4096
4 NTSC DISP LINE 459 0 ~ 4096
5 NTSC CLAMP 1 0 ~ 127
6 NTSC WIDTH 31 0 ~ 63
Group: 501 PAL Gakaku(Composite/Svideo) at I/P OFF
0PAL TOTAL DOTS 1328 0 ~ 4096
1PAL DISP DOTS 1004 0 ~ 4096
2PAL H BACK PORCTH 267 0 ~ 4096
3PAL V BACK PORCTH 63 0 ~ 4096
4PAL DISP LINE 541 0 ~ 4096
5PAL CLAMP 1 0 ~ 127
6PAL WIDTH 31 0 ~ 63
Group: 502 NTSC Gakaku (Composite/Svideo) at I/P ON
0 NTSC TOTAL DOTS 959 0 ~ 4096
1 NTSC DISP DOTS 748 0 ~ 768
2 NTSC H BACK PORCTH 175 0 ~ 4096
3 NTSC V BACK PORCTH 49 0 ~ 4096
4 NTSC DISP LINE 458 0 ~ 576
5 NTSC CLAMP 1 0 ~ 127
6 NTSC WIDTH 31 0 ~ 63
Group: 503 PAL Gakaku(Composite/Svideo) at I/P ON
0PAL TOTAL DOTS 990 0 ~ 4096
1PAL DISP DOTS 748 0 ~ 768
2PAL H BACK PORCTH 201 0 ~ 4096
3PAL V BACK PORCTH 64 0 ~ 4096
4PAL DISP LINE 536 0 ~ 576
5PAL CLAMP 1 0 ~ 127
6PAL WIDTH 31 0 ~ 63
Group: 510 HDTV 1080i-60 Gakaku (Component)
0 HDTV TOTAL DOTS 2243 0 ~ 4096
1 HDTV DISP DOTS 1909 0 ~ 4096
2 HDTV H BACK PORCTH 245 0 ~ 4096
3 HDTV V BACK PORCTH 56 0 ~ 4096
4 HDTV DISP LINE 1050 0 ~ 4096
5 HDTV CLAMP 7 0 ~ 127
6 HDTV WIDTH 58 0 ~ 63
Group: 511HDTV 1080i-50 Gakaku (Component)
0 HDTV TOTAL DOTS 2663 0 ~ 4096
1 HDTV DISP DOTS 1886 0 ~ 4096
2 HDTV H BACK PORCTH 243 0 ~ 4096
3 HDTV V BACK PORCTH 56 0 ~ 4096
4 HDTV DISP LINE 1050 0 ~ 4096
5 HDTV CLAMP 7 0 ~ 127
6 HDTV WIDTH 58 0 ~ 63
Group: 512 HDTV 1035i Gakaku (Component)
0 HDTV TOTAL DOTS 2244 0 ~ 4096
1 HDTV DISP DOTS 1907 0 ~ 4096
2 HDTV H BACK PORCTH 251 0 ~ 4096
3 HDTV V BACK PORCTH 92 0 ~ 4096
4 HDTV DISP LINE 1009 0 ~ 4096
5 HDTV CLAMP 7 0 ~ 127
6 HDTV WIDTH 58 0 ~ 63
Group: 513 HDTV 720p Gakaku (Component)
0 HDTV TOTAL DOTS 1679 0 ~ 4096
1 HDTV DISP DOTS 1270 0 ~ 4096
2 HDTV H BACK PORCTH 321 0 ~ 4096
3 HDTV V BACK PORCTH 34 0 ~ 4096
No. Adjustment Item Initial Value Range Input source / Description
Electrical Adjustments
