Sanyo PLC-SU50 Service Manual

-15-
4 HDTV DISP LINE 700 0 ~ 4096
5 HDTV CLAMP 7 0 ~ 127
6 HDTV WIDTH 58 0 ~ 63
Group: 514 HDTV 575p Gakaku (Component)
0 HDTV TOTAL DOTS 1253 0 ~ 4096
1 HDTV DISP DOTS 952 0 ~ 4096
2 HDTV H BACK PORCTH 249 0 ~ 4096
3 HDTV V BACK PORCTH 61 0 ~ 4096
4 HDTV DISP LINE 536 0 ~ 4096
5 HDTV CLAMP 35 0 ~ 127
6 HDTV WIDTH 58 0 ~ 63
Group: 515 HDTV 480p Gakaku (Component)
0 HDTV TOTAL DOTS 1317 0 ~ 4096
1 HDTV DISP DOTS 1051 0 ~ 4096
2 HDTV H BACK PORCTH 221 0 ~ 4096
3 HDTV V BACK PORCTH 48 0 ~ 4096
4 HDTV DISP LINE 459 0 ~ 4096
5 HDTV CLAMP 35 0 ~ 127
6 HDTV WIDTH 58 0 ~ 63
Group: 516 HDTV 575i Gakaku (Component) at I/P OFF
0 HDTV TOTAL DOTS 1309 0 ~ 4096
1 HDTV DISP DOTS 984 0 ~ 4096
2 HDTV H BACK PORCTH 259 0 ~ 4096
3 HDTV V BACK PORCTH 60 0 ~ 4096
4 HDTV DISP LINE 543 0 ~ 4096
5 HDTV CLAMP 1 0 ~ 127
6 HDTV WIDTH 31 0 ~ 63
Group: 517 HDTV 480i Gakaku (Component)at I/POFF
0 HDTV TOTAL DOTS 1311 0 ~ 4096
1 HDTV DISP DOTS 1023 0 ~ 4096
2 HDTV H BACK PORCTH 216 0 ~ 4096
3 HDTV V BACK PORCTH 49 0 ~ 4096
4 HDTV DISP LINE 458 0 ~ 4096
5 HDTV CLAMP 1 0 ~ 127
6 HDTV WIDTH 31 0 ~ 63
Group: 518 HDTV 575i Gakaku (Component) at I/P ON
0 HDTV TOTAL DOTS 991 0 ~ 4096
1 HDTV DISP DOTS 748 0 ~ 768
2 HDTV H BACK PORCTH 198 0 ~ 4096
3 HDTV V BACK PORCTH 60 0 ~ 4096
4 HDTV DISP LINE 536 0 ~ 576
5 HDTV CLAMP 1 0 ~ 127
6 HDTV WIDTH 31 0 ~ 63
Group: 519 HDTV 480i Gakaku (Component) at I/PON
0 HDTV TOTAL DOTS 959 0 ~ 4096
1 HDTV DISP DOTS 748 0 ~ 768
2 HDTV H BACK PORCTH 158 0 ~ 4096
3 HDTV V BACK PORCTH 50 0 ~ 4096
4 HDTV DISP LINE 455 0 ~ 576
5 HDTV CLAMP 1 0 ~ 127
6 HDTV WIDTH 31 0 ~ 63
Group: 520 RGB 1080i-60 Gakaku
0 RGB TOTAL DOTS 2298 0 ~ 4096
1 RGB DISP DOTS 1953 0 ~ 4096
2 RGB H BACK PORCTH 264 0 ~ 4096
3 RGB V BACK PORCTH 81 0 ~ 4096
4RGB DISP LINE 1050 0 ~ 4096
5 RGB CLAMP 40 0 ~ 127
6 RGB WIDTH 58 0 ~ 63
Group: 521 RGB 1080i-50 Gakaku
0 RGB TOTAL DOTS 2735 0 ~ 4096
1 RGB DISP DOTS 1938 0 ~ 4096
2 RGB H BACK PORCTH 261 0 ~ 4096
3 RGB V BACK PORCTH 55 0 ~ 4096
4RGB DISP LINE 1050 0 ~ 4096
5 RGB CLAMP 40 0 ~ 127
6 RGB WIDTH 58 0 ~ 63
Group: 522 RGB 1035i Gakaku
0 RGB TOTAL DOTS 2261 0 ~ 4096
1 RGB DISP DOTS 1920 0 ~ 4096
2 RGB H BACK PORCTH 260 0 ~ 4096
3 RGB V BACK PORCTH 92 0 ~ 4096
4RGB DISP LINE 1012 0 ~ 4096
5 RGB CLAMP 40 0 ~ 127
6 RGB WIDTH 58 0 ~ 63
