Sanyo PLC-SU50 Service Manual

-16-
Group: 523 RGB 720p Gakaku
0 RGB TOTAL DOTS 2203 0 ~ 4096
1 RGB DISP DOTS 1666 0 ~ 4096
2RGB H BACK PORCTH 410 0 ~ 4096
3 RGB V BACK PORCTH 35 0 ~ 4096
4RGB DISP LINE 700 0 ~ 4096
5 RGB CLAMP 50 0 ~ 127
6 RGB WIDTH 58 0 ~ 63
Group: 524 RGB 575p Gakaku
0 RGB TOTAL DOTS 1385 0 ~ 4096
1 RGB DISP DOTS 1052 0 ~ 4096
2RGB H BACK PORCTH 263 0 ~ 4096
3 RGB V BACK PORCTH 62 0 ~ 4096
4RGB DISP LINE 535 0 ~ 4096
5 RGB CLAMP 7 0 ~ 127
6 RGB WIDTH 58 0 ~ 63
Group: 525 RGB 480p Gakaku
0 RGB TOTAL DOTS 1309 0 ~ 4096
1 RGB DISP DOTS 1046 0 ~ 4096
2RGB H BACK PORCTH 211 0 ~ 4096
3 RGB V BACK PORCTH 55 0 ~ 4096
4RGB DISP LINE 560 0 ~ 4096
5 RGB CLAMP 7 0 ~ 127
6 RGB WIDTH 26 0 ~ 63
Group: 526 RGB 575i Gakaku
0 RGB TOTAL DOTS 1314 0 ~ 4096
1 RGB DISP DOTS 992 0 ~ 4096
2RGB H BACK PORCTH 256 0 ~ 4096
3 RGB V BACK PORCTH 65 0 ~ 4096
4RGB DISP LINE 539 0 ~ 4096
5 RGB CLAMP 1 0 ~ 127
6 RGB WIDTH 32 0 ~ 63
Group: 527 RGB 480i Gakaku
0 RGB TOTAL DOTS 1313 0 ~ 4096
1 RGB DISP DOTS 1024 0 ~ 4096
2RGB H BACK PORCTH 216 0 ~ 4096
3 RGB V BACK PORCTH 48 0 ~ 4096
4RGB DISP LINE 459 0 ~ 4096
5 RGB CLAMP 1 0 ~ 127
6 RGB WIDTH 32 0 ~ 63
Group: 530 SCART 575i Gakaku at I/P OFF
0 SCART TOTAL DOTS 1313 0 ~ 4096
1 SCART DISP DOTS 985 0 ~ 4096
2 SCART H BACK PORCTH 243 0 ~ 4096
3 SCART V BACK PORCTH 70 0 ~ 4096
4 SCART DISP LINE 514 0 ~ 4096
5 SCART CLAMP 1 0 ~ 127
6 SCART WIDTH 32 0 ~ 63
Group: 531
SCART 480i Gakaku at I/P OFF
0 SCART TOTAL DOTS 1296 0 ~ 4096
1 SCART DISP DOTS 1042 0 ~ 4096
2 SCART H BACK PORCTH 211 0 ~ 4096
3 SCART V BACK PORCTH 46 0 ~ 4096
4 SCART DISP LINE 450 0 ~ 4096
5 SCART CLAMP 1 0 ~ 127
6 SCART WIDTH 32 0 ~ 63
Group: 532 SCART 575i Gakaku at I/P ON
0 SCART TOTAL DOTS 998 0 ~ 4096
1 SCART DISP DOTS 748 0 ~ 768
2 SCART H BACK PORCTH 187 0 ~ 4096
3 SCART V BACK PORCTH 70 0 ~ 4096
4 SCART DISP LINE 514 0 ~ 576
5 SCART CLAMP 1 0 ~ 127
6 SCART WIDTH 32 0 ~ 63
Group: 533 SCART 480i Gakaku at I/P ON
0 SCART TOTAL DOTS 940 0 ~ 4096
1 SCART DISP DOTS 748 0 ~ 768
2 SCART H BACK PORCTH 155 0 ~ 4096
3 SCART V BACK PORCTH 44 0 ~ 4096
4 SCART DISP LINE 452 0 ~ 576
5 SCART CLAMP 1 0 ~ 127
6 SCART WIDTH 32 0 ~ 63
No. Adjustment Item Initial Value Range Input source / Description
Electrical Adjustments
