Sanyo PLC-SU50

PH3-SL2000, PG3-XL2000
-27-
Electrical Parts List
C657 403 157 6404 CERAMIC 330P K 50V
C658 403 157 6404 CERAMIC 330P K 50V
C659 403 218 8101 ELECT 1000U M 25V
C691 403 233 0401 ELECT 330U M 25V
C693 403 206 9004 ELECT 1000U M 6.3V
C694 403 206 9004 ELECT 1000U M 6.3V
RESISTOR
!R601 401 287 5700 MT-GLAZE 220K JA 1W
R61A 401 275 2902 MT-GLAZE 68K JA 1W
R61B 401 275 2902 MT-GLAZE 68K JA 1W
R61E 401 275 2902 MT-GLAZE 68K JA 1W
R61F 401 275 2902 MT-GLAZE 68K JA 1W
R611 402 088 0307 RESISTER 0.15 KA 2W
R612 402 088 0307 RESISTER 0.15 KA 2W
R615 401 242 3901 MT-GLAZE 240K JA 1/2W
R616 401 242 3901 MT-GLAZE 240K JA 1/2W
R617 401 259 9002 MT-GLAZE 150K FA 1/2W
R618 401 259 9002 MT-GLAZE 150K FA 1/2W
R619 401 259 9002 MT-GLAZE 150K FA 1/2W
R62A 401 105 1501 MT-GLAZE 1.5K JA 1/16W
R62B 401 105 0603 MT-GLAZE 10K JA 1/16W
R62C 401 105 5509 MT-GLAZE 470K JA 1/16W
R62D 401 105 3802 MT-GLAZE 30K JA 1/16W
R62E 401 113 5805 MT-GLAZE 1.1K JA 1/16W
R62F 401 218 4406 MT-GLAZE 1.2K FA 1/16W
R62G 401 105 0405 MT-GLAZE 100 JA 1/16W
R62H 401 105 4007 MT-GLAZE 330 JA 1/16W
R62I 401 158 4108 MT-GLAZE 4.7 JA 1/16W
R62J 401 105 1907 MT-GLAZE 180 JA 1/16W
R62L 401 113 6109 MT-GLAZE 2.4K JA 1/16W
R62M 401 105 4502 MT-GLAZE 390 JA 1/16W
R62P 401 105 5400 MT-GLAZE 47K JA 1/16W
R62Q 401 105 2607 MT-GLAZE 22 JA 1/16W
R62R 401 177 2208 MT-GLAZE 5.6M JA 1/16W
R62T 401 105 3000 MT-GLAZE 220K JA 1/16W
R620 401 259 9002 MT-GLAZE 150K FA 1/2W
R623 401 105 5301 MT-GLAZE 4.7K JA 1/16W
!R631 424 006 1302 FUSE 250V 2.5A
!R633 402 079 7803 FUSIBLE RES 22 JH 1/4W
R634 401 238 4509 MT-GLAZE 47 JA 1/3W
R635 401 105 0504 MT-GLAZE 1K JA 1/16W
R636 401 257 7406 MT-GLAZE 120 JA 1/3W
R637 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R638 401 105 0603 MT-GLAZE 10K JA 1/16W
R639 401 113 6109 MT-GLAZE 2.4K JA 1/16W
R641 401 105 2805 MT-GLAZE 2.2K JA 1/16W
R646 401 111 6309 MT-GLAZE 470 JA 1/2W
R647 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R648 401 105 1600 MT-GLAZE 15K JA 1/16W
R651 401 105 0504 MT-GLAZE 1K JA 1/16W
R652 401 105 0306 MT-GLAZE 10 JA 1/16W
R653 401 186 0202 MT-GLAZE 10K DA 1/16W
R654 401 185 9305 MT-GLAZE 560 DA 1/16W
R655 401 185 9503 MT-GLAZE 6.8K DA 1/16W
R656 401 105 3208 MT-GLAZE 270 JA 1/16W
R657 401 105 0504 MT-GLAZE 1K JA 1/16W
R658 401 105 0504 MT-GLAZE 1K JA 1/16W
R659 401 105 0504 MT-GLAZE 1K JA 1/16W
R660 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R661 401 105 0603 MT-GLAZE 10K JA 1/16W
R662 401 230 8000 MT-GLAZE 1K JA 1/3W
R663 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R664 401 105 0603 MT-GLAZE 10K JA 1/16W
VARIABLE RESISTOR
!VA601 408 018 9808 VARISTOR ENC471D-14AS
VR611 645 025 7414 VR,SEMI,1K S
TRANSFORMER
TSW611 645 063 8756 THERMOSTATS
!T651 645 030 7126 TRANS,POWER,PULSE
COIL
!L601 645 050 2231 LINE FILTER
!L611 645 048 3899 LINE FILTER
L612 645 062 3561 INDUCTOR,900U
L694 645 059 2065 INDUCTOR,10U K
DIODE
DB611 407 202 7705 DIODE D10XB60
DS643 407 219 0805 THYRISTOR TF861S
D611 407 191 3900 DIODE FML-G16S
D612 407 149 6304 DIODE SFPB-54V
D616 407 149 0807 DIODE 1SS355-TE-17
D617 407 149 0807 DIODE 1SS355-TE-17
D618 407 149 0807 DIODE 1SS355-TE-17
D619 407 149 0807 DIODE 1SS355-TE-17
D62R 407 149 0807 DIODE 1SS355-TE-17
D631 407 190 4106 DIODE SFPL-52V
D633 407 187 8209 ZENER DIODE UDZ12B-TE-17
D636 407 226 7101 DIODE SC311-06
D651 407 222 9604 DIODE FMB-2306
D652 407 222 9703 DIODE FMJ-23L
D653 407 190 4106 DIODE SFPL-52V
D654 407 209 1201 ZD UDZS-TE-176.2B
MISCELLANEOUS
FB611 610 229 3531 CORE
FB613 610 229 3531 CORE
FB691 610 229 3531 CORE
FB693 610 229 3531 CORE
!F601 423 021 7801 FUSE 250V 6.3A
F601A 645 000 5077 HOLDER,FUSE
F601B 645 000 5077 HOLDER,FUSE
!PC641 407 223 7302 PC TLP421F(D4-GB-TP4)
407 223 8309 PC TLP421F(D4-GR-TP4)
!PC642 407 223 7302 PC TLP421F(D4-GB-TP4)
407 223 8309 PC TLP421F(D4-GR-TP4)
!PC643 407 223 7302 PC TLP421F(D4-GB-TP4)
407 223 8309 PC TLP421F(D4-GR-TP4)
PTH611 408 037 5508 THERMISTOR NTH11D5R0LC
610 310 3143 ASSY,PWB,LAMP COVER SW MA
MISCELLANEOUS
SW901 645 063 8077 SWITCH,PUSH 2P-2TX3
DIFFERENCES BETWEEN PH3-SL2000 AND PG3-
XL2000
PH3-SL2000 610 309 5592 ASSY,PWB,MAIN MH3A
PG3-XL2000 610 311 1605 ASSY,PWB,MAIN MG3A
Differential Parts are indicated below list.
TRANSISTOR
Q1201 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
MAIN BOARD
LAMP COVER SW BOARD
Key No. Part No. Description Key No. Part No. Description
