PH3-SL2000, PG3-XL2000
-21-
Electrical Parts List
(PH3-SL2000)
! 610 306 726 1 ASSY,PWB,AV MA7A
! 610 306 7278 ASSY,PWB,DVI MA7A
! 610 310 3136 ASSY,PWB,POWER MA7A
! 610 310 3143 ASSY,PWB,LAMP COVER SW MA
! 610 309 5592 ASSY,PWB,MAIN MH3A
! 610 309 5608 ASSY,PWB,RC MZ3A
(PG3-XL2000)
! 610 306 7261 ASSY,PWB,AV MA7A
! 610 306 7278 ASSY,PWB,DVI MA7A
! 610 310 3143 ASSY,PWB,LAMP COVER SW MA
! 610 310 3167 ASSY,PWB,POWER MT3A
! 610 311 1605 ASSY,PWB,MAIN MG3A
! 610 311 1612 ASSY,PWB,RC MY3A
(PH3-SL2000)
!LF901 645 062 3134 UNIT,NOISE FILTER
!LP900 610 307 7925 COMPL,OPTICAL LAMP MA7A
!A901 645 062 5480 UNIT,BALLAST
A901A 610 309 1617 CABLE,BALLAST
!FN901 645 054 9120 MOTOR,FAN DC 2.64W
!FN902 645 062 3059 MOTOR,FAN DC 2.40W
!FN903 645 062 3042 MOTOR,FAN DC 2.16W
!FN904 645 062 3110 MOTOR,FAN DC 2.16W
!FN905 645 062 3103 MOTOR,FAN DC 3.6W
!FN906 645 062 3103 MOTOR,FAN DC 3.6W
MAIN&FAN 610 306 8336 STANDARD WIRE ASSY-JPN
SP901 645 049 0736 SPEAKER,8
!SW902 645 050 3580 SWITCH,THERMAL
WK8D-28D 645 053 2566 CORD,ID CONNECTOR
(PG3-XL2000)
!LF901 645 062 3134 UNIT,NOISE FILTER
!LP900 610 309 2706 COMPL,OPTICAL LAMP MT3A
!A901 645 058 3520 UNIT,BALLAST
A901A 610 308 8822 CABLE,BALLAST
!FN901 645 054 9120 MOTOR,FAN DC 2.64W
!FN902 645 062 3059 MOTOR,FAN DC 2.40W
!FN903 645 062 3042 MOTOR,FAN DC 2.16W
!FN904 645 062 3110 MOTOR,FAN DC 2.16W
!FN905 645 062 3103 MOTOR,FAN DC 3.6W
!FN906 645 062 3103 MOTOR,FAN DC 3.6W
MAIN&FAN 610 306 8336 STANDARD WIRE ASSY-JPN
SP901 645 049 0736 SPEAKER,8
!SW902 645 050 3580 SWITCH,THERMAL
WK8D-28D 645 053 2566 CORD,ID CONNECTOR
610 306 7261 ASSY,PWB,AV MA7A
TRANSISTOR
Q001 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q002 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q051 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q052 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q053 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q054 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q1001 405 134 5905 TR 2SA1037AK-T146-R
405 147 2205 TR 2SA1037AK-S-T146
405 002 0308 TR 2SA1037K T146 R
405 002 0407 TR 2SA1037K T146 S
405 002 6706 TR 2SA1179-M6-TB
405 002 6904 TR 2SA1179-M7-TB
405 163 1503 TR 2SA1179N-M6-TB
405 163 2708 TR 2SA1179N-M7-TB
405 173 9605 TR 2SA1235A1E
405 173 9704 TR 2SA1235A1F
Q1002 405 134 5905 TR 2SA1037AK-T146-R
405 147 2205 TR 2SA1037AK-S-T146
405 002 0308 TR 2SA1037K T146 R
405 002 0407 TR 2SA1037K T146 S
405 002 6706 TR 2SA1179-M6-TB
405 002 6904 TR 2SA1179-M7-TB
405 163 1503 TR 2SA1179N-M6-TB
405 163 2708 TR 2SA1179N-M7-TB
405 173 9605 TR 2SA1235A1E
405 173 9704 TR 2SA1235A1F
Q1003 405 134 5905 TR 2SA1037AK-T146-R
AV BOARD
OUT OF CIRCUIT BOARDS
ASSEMBLIED BOARDS
Key No. Part No. Description Key No. Part No. Description
