PH3-SL2000, PG3-XL2000
-43-
Electrical Parts List
D3884 407 149 0807 DIODE 1SS355-TE-17
D4812 407 223 1102 ZENER DIODE 02DZ6.2Y(TPH3
D4813 407 223 1102 ZENER DIODE 02DZ6.2Y(TPH3
D4891 407 149 0807 DIODE 1SS355-TE-17
D491 407 149 0807 DIODE 1SS355-TE-17
D5301 407 149 0807 DIODE 1SS355-TE-17
D65B 407 149 0807 DIODE 1SS355-TE-17
D651 407 232 0400 ZENER DIODE UDZS2.0B-TE-1
407 187 7103 ZENER DIODE UDZ2.0B-TE-17
D652 401 259 1501 MT-GLAZE 2.2 JA 1/3W
D6601 407 149 0807 DIODE 1SS355-TE-17
D6603 407 149 0807 DIODE 1SS355-TE-17
D6607 407 149 0807 DIODE 1SS355-TE-17
D6608 407 149 0807 DIODE 1SS355-TE-17
D6609 407 149 0807 DIODE 1SS355-TE-17
D6611 407 149 0807 DIODE 1SS355-TE-17
D6613 407 149 0807 DIODE 1SS355-TE-17
D6614 407 149 0807 DIODE 1SS355-TE-17
D6641 407 149 0807 DIODE 1SS355-TE-17
D6651 407 149 0807 DIODE 1SS355-TE-17
D67P 407 206 6308 ZD UDZS-TE-175.1B
407 179 1706 ZENER DIODE UDZ5.1B-TE-17
D67Q 407 149 0807 DIODE 1SS355-TE-17
D671 407 201 2701 DIODE RB051L-40-TE25
D68P 407 206 6308 ZD UDZS-TE-175.1B
407 179 1706 ZENER DIODE UDZ5.1B-TE-17
D68Q 407 149 0807 DIODE 1SS355-TE-17
D6801 407 209 1201 ZD UDZS-TE-176.2B
407 179 0501 ZENER DIODE UDZ6.2B-TE-17
D6802 407 209 1201 ZD UDZS-TE-176.2B
407 179 0501 ZENER DIODE UDZ6.2B-TE-17
D6803 407 209 1201 ZD UDZS-TE-176.2B
407 179 0501 ZENER DIODE UDZ6.2B-TE-17
D6804 407 209 1201 ZD UDZS-TE-176.2B
407 179 0501 ZENER DIODE UDZ6.2B-TE-17
D681 407 201 2701 DIODE RB051L-40-TE25
D6831 407 209 7500 LED SML-210YT T86 L
D6832 407 203 7803 LED SML-210LT T86 M
D6833 407 199 1809 LED SML-020MLT-T86
D6841 407 221 7106 ZENER DIODE UDZS-TE-1712B
407 187 8209 ZENER DIODE UDZ12B-TE-17
D6842 407 221 7106 ZENER DIODE UDZS-TE-1712B
407 187 8209 ZENER DIODE UDZ12B-TE-17
D6843 407 221 7106 ZENER DIODE UDZS-TE-1712B
407 187 8209 ZENER DIODE UDZ12B-TE-17
D6844 407 221 7106 ZENER DIODE UDZS-TE-1712B
407 187 8209 ZENER DIODE UDZ12B-TE-17
D69A 407 004 0706 DIODE DCB015-TB
D69B 407 004 0706 DIODE DCB015-TB
D69C 407 149 0807 DIODE 1SS355-TE-17
D69D 407 149 0807 DIODE 1SS355-TE-17
D801 407 149 0807 DIODE 1SS355-TE-17
D802 407 149 0807 DIODE 1SS355-TE-17
D8101 407 201 2701 DIODE RB051L-40-TE25
D8102 407 149 0807 DIODE 1SS355-TE-17
D8121 407 201 2701 DIODE RB051L-40-TE25
D8122 407 149 0807 DIODE 1SS355-TE-17
D856 407 149 0807 DIODE 1SS355-TE-17
D857 407 149 0807 DIODE 1SS355-TE-17
MISCELLANEOUS
!IC65A 645 062 3127 UNIT,POWER(DC)
SW6801 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6802 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6803 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6804 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6806 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6807 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6808 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6809 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6811 645 026 2791 SWITCH,PUSH 1P-1TX1
X1321 645 047 6587 OSC,CRYSTAL 26.000MHZ
X1331 645 047 6587 OSC,CRYSTAL 26.000MHZ
X301 645 041 5708 OSC,CRYSTAL 14.31818MHZ
X3101 645 047 1568 OSC,CRYSTAL 16.200MHZ
X5351 645 053 7677 OSC,CERAMIC 503.0KHZ
X851 645 030 5436 OSC,CRYSTAL 12.288MHZ
X9811 645 035 8906 OSC,CRYSTAL 48MHZ
(PH3-SL2000) 610 309 5608 ASSY,PWB,RC MZ3A
(PG3-XL2000) 610 311 1612 ASSY,PWB,RC MY3A
There is no defferential parts on the EC board.
CAPACITOR
C2821 403 283 6309 CERAMIC 1U Z 10V
C2822 403 157 6602 CERAMIC 470P K 50V
RESISTOR
R2821 401 105 5103 MT-GLAZE 47 JA 1/16W
R2822 401 105 0405 MT-GLAZE 100 JA 1/16W
MISCELLANEOUS
A2801 645 056 9111 UNIT,REMOCON RECEIVER
645 063 6943 CABLE,USB
645 061 5115 CABLE,USB
645 063 6936 CABLE,USB
610 296 6558 STRAP COMP-MW6P
610 307 6317 FILTER BASE F-MA7A
610 307 6324 FILTER BASE B-MA7A
645 061 5122 CABLE,INTERFACE DVI-VGA
OWNER'S MANUAL
(English) 610 312 1291 OWNER'S MANUAL-PG3A
(Germany) 610 312 1307 OWNER'S MANUAL-PG3A-D
(French) 610 312 1314 OWNER'S MANUAL-PG3A-F
(Italy) 610 312 1321 OWNER'S MANUAL-PG3A-I
(Spanish) 610 312 1338 OWNER'S MANUAL-PG3A-E
RC
645 061 4255 ASSY,REMOCON CXMJ
610 307 6461 RC-BATTERY LID-CXMJ
!AC CORD
(EU) 645 002 9196 CORD,POWER-3.0MK,EU
ACCESSORIES
RC BOARD
Key No. Part No. Description Key No. Part No. Description
To Next Page
