A1
KJ8-WL250000 / KJ8-WL250100
Schematic Diagrams
Printed Wiring Board Drawings
Model Chassis No.
PLC-WL2500 KJ8-WL250000
PLC-WL2501 KJ8-WL250100
Diagrams & Drawings
These schematic diagrams and printed wiring board drawings are part of
the service manual original for chassis No. KJ8-WL250000 / KJ8-WL250100
models PLC-WL2500 / PLC-WL2501.
File with the service manual No. SM5111262-00
Note:
All the information of part numbers and values indicated on these diagrams are at the
beginning of production. To improve the performance, there may be some differences to
the actual set. When you order the service parts, use service parts code mentioned on the
parts list in this service manual.
