Sanyo PLC-XU101 Service Manual

KL6-XU10100
Electrical Parts List
-68-
Electrical Parts List
Note: Parts order must contain Chassis No., Part No., and Descriptions.
Key No. Part No. Description Key No. Part No. Description
ASSEMBLED BOARDS
! 610 333 8187 ASSY,PWB,POWER KM6AC
! 610 333 8224 ASSY,PWB,LINE FILTER KM6AC
! 610 333 8101 ASSY,PWB,LAMP COVER SW. KM6AC
! 610 333 8132 ASSY,PWB,AV KL6AC
! 610 333 7920 ASSY,PWB,MAIN KL6AC
! 610 333 8064 ASSY,PWB,R/CS. KL6AC
! 610 333 7951 ASSY,PWB,TEMP KL6AC
OUT OF CIRCUIT BOARD
! A901 645 093 3134 UNIT,BALLAST+CV
L901 945 023 4959 CORE,CLAMP
! LF901 645 091 5765 UNIT,NOISE FILTER
! LP900 610 333 9740 LAMP, POA-LMP111
! FN901 645 091 3693 MOTOR,FAN DC 2.40W
! FN902 645 091 3693 MOTOR,FAN DC 2.40W
! FN903 945 072 0957 MOTOR,FAN DC 2.76W
! FN904 945 088 7674 MOTOR,BLW DC 2.88W
! FN905 945 088 7674 MOTOR,BLW DC 2.88W
! FN907 945 087 8948 MOTOR,BLW DC 2.88W
SP901 952 001 6157 SPEAKER,8
652 002 3055 SPEAKER,8
! SW902 945 048 3159 SWITCH,THERMAL(100DEG)
610 333 8187 ASSY,PWB,POWER KM6AC
TRANSISTOR
Q601 405 218 6002 TR 2SK3934 LBS1
Q602 405 218 6002 TR 2SK3934 LBS1
Q621 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q622 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 002 0311 TR 2SA1037K T146 R
305 002 0410 TR 2SA1037K T146 S
305 002 6729 TR 2SA1179-M6-TB
305 002 6927 TR 2SA1179-M7-TB
305 163 1516 TR 2SA1179N-M6-TB
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
Q651 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 002 0311 TR 2SA1037K T146 R
305 002 0410 TR 2SA1037K T146 S
305 002 6729 TR 2SA1179-M6-TB
305 002 6927 TR 2SA1179-M7-TB
305 163 1516 TR 2SA1179N-M6-TB
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
Q652 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q681 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q682 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
INTEGRATED CIRCUIT
IC601 309 523 1413 IC FA5502M
IC651 309 558 4202 IC STR-Z2156A
IC681 309 344 6522 IC UPC1093T-E1
CAPACITOR
C607 303 371 8518 MT-POLYEST 1U K 400V
303 427 2019 MT-POLYEST 1U K 400V
303 451 4119 MT-POLYEST 1U K 450V
C608 303 222 1326 CERAMIC 1000P K 1K
C609 303 222 1326 CERAMIC 1000P K 1K
C611 303 371 8518 MT-POLYEST 1U K 400V
303 427 2019 MT-POLYEST 1U K 400V
303 451 4119 MT-POLYEST 1U K 450V
C612 303 433 2812 ELECT 220U M 35V
C613 303 410 7113 ELECT 100U M 25V
C614 303 410 7113 ELECT 100U M 25V
C616 404 115 2704 ELECT 330U M 420V
404 115 6306 ELECT 330U M 420V
C618 303 427 1814 MT-POLYEST 0.1U K 450V
C619 303 298 9612 CERAMIC 0.1U K 16V
C621 303 205 2811 CERAMIC 0.047U K 25V
C622 303 157 6417 CERAMIC 330P K 50V
C623 303 215 2214 CERAMIC 0.01U K 50V
C624 303 342 3313 CERAMIC 0.1U K 25V
C625 303 402 3918 ELECT 4.7U M 50V
C626 303 342 3313 CERAMIC 0.1U K 25V
C627 303 342 3313 CERAMIC 0.1U K 25V
C628 303 157 3317 CERAMIC 68P J 50V
C629 303 157 6615 CERAMIC 470P K 50V
C631 303 298 9612 CERAMIC 0.1U K 16V
C632 303 342 3313 CERAMIC 0.1U K 25V
C633 303 342 3313 CERAMIC 0.1U K 25V
C636 303 427 1814 MT-POLYEST 0.1U K 450V
C650 303 342 3313 CERAMIC 0.1U K 25V
C651 303 268 7013 TA-SOLID 2.2U M 35V
C652 303 256 2419 CERAMIC 0.22U Z 50V
C653 303 113 3818 CERAMIC 1000P K 50V
C654 303 247 3319 CERAMIC 330P K 2K
C656 303 342 3313 CERAMIC 0.1U K 25V
C657 303 218 8817 CERAMIC 220P K 2K
C658 303 083 4310 POLYPRO 0.022U J 400V
C659 303 157 6813 CERAMIC 680P K 50V

Sanyo PLC-XU101 Specifications

General

Matrix size	0.8 \
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	500:1
Screen size compatibility	33 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	±40 °
Output	D-Sub15 x 1
Video in	RCA x 1
Audio input	Yes
Aspect ratio	4:3
Dimensions (WxDxH)	334 x 232 x 78 mm
Connectivity technology	Wired
Lamp power	275 W
Light source type	Lamp
Noise level	29 dB
Dot clock scanning frequency	140 MHz
Audio (L/R) in	2
Headphone outputs	1
Display resolution	786 x 432 pixels
Power consumption (typical)	385 W

Weight and Dimensions

Weight	3500 g
