Sanyo PLC-XU101 Service Manual

KL6-XU10100
-93-
Mechanical Parts List
CABINET PARTS
C01 610 331 6413 ASSY,STAND LEG-KM6A
C02 610 333 9276 BUTTON-KM6AC
C03 610 333 8682 CABINET TOP-KL6AC
C04 610 333 9566 CABINET FRONT-KL6AC
C05 610 333 9054 CABINET BOTTOM-KL6AC
C06 610 333 8729 CAP LENS-KM6AC
C07 610 333 9269 CAP LENS BASE-KM6AC
C08 610 333 8798 COVER ,LP SERVICE-KM6AC
C09 610 333 9207 DEC INLAY LED-KL6AC
C10 910 325 2477 DEC LEG-PT5EC
C11 910 302 5613 DEC SHEET-M4JA
C12 610 333 9290 FILTER BASE-KM6AC
C13 610 333 8576 GRILLE-KM6AC
C14 610 333 9344 SPRING CAP-KM6AC
CHASSIS PARTS
M01 610 333 9252 DEC AV SHEET-KL6AC
M02 610 334 4348 HOLDER POWER PWB BTM-KM6AC
M03 610 334 5895 HOLDER T SW-KM6AC
M04 610 334 0265 MOUNTING DUCT BTM-KM6AC
M05 610 334 0258 MOUNTING DUCT TOP-KM6AC
M06 610 334 4386 MOUNTING DUCT LP-KM6AC
M07 610 333 9634 PANEL AV-KM6AC
M08 610 334 0067 SPACER SHEET#POWER T-KM6AC
M09 610 334 7097 SPACER SHEET#POW T TOP-KM6AC
M10 610 331 1692 OPTICAL BASE BTM-KM6A
M11 610 331 1715 OPTICAL BASE TOP A-KM6A
M12 610 331 1722 OPTICAL BASE TOP B-KM6A
SCREWS
S01 411 190 5001 SCR S-TPG BIN 3X10
S02 411 200 2808 SCR TPG FLT 3X8
S03 411 189 6507 BOLT HEX-SCT+SW+W 2.5X5
S04 312 069 7105 SPECIAL SCREW V
S05 312 070 3400 SPECIAL SCREW-3.0X10V
OPTICAL PARTS
L01 645 092 9892 PRISM(PBS)
L02 610 335 2084 ASSY,LCD PNL/PRISM -KM6AC
(Including Key No. L02-1 to L02-5 and LCD Panels)
L02-1 645 089 3506 POLARIZED GLASS(OUT/R)
L02-2 645 089 3513 POLARIZED GLASS(OUT/G)
L02-3 645 089 3520 POLARIZED GLASS(OUT/B)
L02-4 645 089 4091 PREPOLARIZED GLASS(OUT/G)
L02-5 645 089 4107 PREPOLARIZED GLASS(OUT/B)
L03 945 061 3945 LENS,PROJECTION
L04 945 088 7797 LENS,INTEGRATOR(IN)
L05 945 088 7803 LENS,INTEGRATOR(OUT)
L06 945 088 7827 LENS,CONDENSER(OUT)
L07 945 088 7834 LENS,CONDENSER(G)
L08 945 088 7841 LENS,CONDENSER(B)
L09 945 088 7858 LENS,CONDENSER(R)
L10 945 088 7865 LENS,RELAY(IN)
L11 945 088 7872 LENS,RELAY(OUT)
L12 945 088 7889 MIRROR(B)
L13 945 088 7896 MIRROR(R)
L14 645 089 3476 POLARIZED GLASS(IN/R)
L15 645 089 3483 POLARIZED GLASS(IN/G)
L16 645 089 3490 POLARIZED GLASS(IN/B)
L17 945 088 7902 DICHROIC MIRROR (B)
L18 945 088 7919 DICHROIC MIRROR (G)
Key No. Part No. Description
Key No. Part No. Description
Mechanical Parts List
Note: Parts order must contain Chassis No., Part No., and Descriptions.

Sanyo PLC-XU101 Specifications

General

Matrix size	0.8 \
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	500:1
Screen size compatibility	33 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	±40 °
Output	D-Sub15 x 1
Video in	RCA x 1
Audio input	Yes
Aspect ratio	4:3
Dimensions (WxDxH)	334 x 232 x 78 mm
Connectivity technology	Wired
Lamp power	275 W
Light source type	Lamp
Noise level	29 dB
Dot clock scanning frequency	140 MHz
Audio (L/R) in	2
Headphone outputs	1
Display resolution	786 x 432 pixels
Power consumption (typical)	385 W

Weight and Dimensions

Weight	3500 g
