Sanyo PLC-XU106

-45-
Electrical Adjustments
Group/
Item
Item Name Function Initial Range Note
3 GAIN AREA V START
White Level Acquiring Area V-Start
Position
500 0 - 1000
4 Image AREA H WIDTH Black/White Level Acquiring Area 13 0 - 4095
5 Image AREA V HIGHT
Black/White Level Acquiring Area
Height
9 0 - 4095
6 OFFSET target Target Value of Black Level Adj. 3 0 - 127
7 OFFSET torelance Torelance of Black Level Adj. 1 1 - 127
8 GAIN target Target Value of White Level Adj. 238 0 - 255
9 GAIN torelance Torelance of White Level Adj. 1 1 - 255
Group
262
Auto Calibration (CVBS/SVIDEO)
0 Y Image Area Start X Y Acquiring Area H-Start Position 20 0 - 1000
1 Y Image Area Start Y Y Acquiring Area V-Start Position 200 0 - 1000
2 Cb Image Area Start X Cb Acquiring Area H-Start Position 500 0-1000
3 Cb Image Area Start Y Cb Acquiring Area V-Start Position 500 0-1000
4 Cr Image Area Start X Cr Acquiring Area H-Start Position 500 0-1000
5 Cr Image Area Start Y Cr Acquiring Area V-Start Position 500 0-1000
6 Image Area H Width Image Level Acquiring Area 8 0 - 4095
7 Image Area V Hight Image Level Acquiring Area Height 9 0 - 4095
8 Y Target Level Target Value of Y Level Adj. 217 0 - 255
9 Cb Target Level Target Value of Cb Level Adj. 217 0-255
10 Cr Target Level Target Value of C Level Adj. 217 0-255
11 Gain Tolerance Torelance of Level Adj. 1 0 - 255
12 Delta Gain Deviation Width of Gain Value 9 0 - 255
Group
264
Auto Calibration (YCbCr)
0 Y-OFFSET AREA H START
Y - Offset Acquiring Area H-Start
Position
925 0 - 1000
1 Y-OFFSET AREA V START
Y - Offset Acquiring Area V-Start
Position
500 0 - 1000
2
CB - OFFSET AREA H
START
CB - Offset Acquiring Area H-Start
Position
925 0 - 1000 If not used: use Y's value
3
CB - OFFSET AREA V
START
CB - Offset Acquiring Area V-Start
Position
500 0 - 1000 If not used: use Y's value
4
CR - OFFSET AREA H
START
CR - Offset Acquiring Area H-Start
Position
925 0 - 1000 If not used: use Y's value
5
CR - OFFSET AREA V
START
CR - Offset Acquiring Area V-Start
Position
500 0 - 1000 If not used: use Y's value
6 Y - GAIN AREA H START 50 0 - 1000
7 Y - GAIN AREA V START 500 0 - 1000
8 CB - GAIN AREA H START 800 0 - 1000
9 CB - GAIN AREA V START 500 0 - 1000
10 CR - GAIN AREA H START 700 0 - 1000
11 CR - GAIN AREA V START 500 0 - 1000
12 Image AREA H WIDTH YCBCR Level Acquiring Area 8 0 - 4095
13 Image AREA V HIGHT YCBCR Level Acquiring Area Height 9 0 - 4095
14 Y - OFFSET TARTGET 4 0 - 255
15 CB OFFSET TARGET 128 0 - 255
16 CR OFFSET TARGET 128 0 - 255
17 Y - GAIN TARGET 217 0 - 255
18 CB - GAIN TARGET 237 0 - 255
19 CR - GAIN TARGET 237 0 - 255
20 OFFSET torelance Torelance of OFFSET Adj. 1 1 - 255
21 GAIN torelance Torelance of GAIN Adj. 1 1 - 255
Group
280
AutoPC Adjsut
0 AutoPCAdjustEnable
Auto-PC Adj Operation Enable if Un-
supported Signal Input
0 0 - 1 0: Enable, 1: Disable
1 Frequency Step Frequency Steps of TotalDot 1 0-3
2 Frequency Threshold Total Dot Freqency Threshold 5 0 - 10 0 [] <--- -----> 10[Not matched]
3 Fine Phase Do Phase Adj after Total Dot Adj. 1 0 - 1
0: Executes Fine Phase, 1: Not
Execute
4 BLKDET Black Level Detection Area 1 0 - 3
5 PHASEMSK Phase Detection Filter 0 0 - 3
0: Effective All Bit,
1: Disable Lower 1 bit
2: Disable Lower 2 bit, 3: Disable
Lower 3 bit
Group
290
PanelType * Panel Type Check
