KB8-XU10600
Electrical Parts List
-68-
Key No. Part No. Description Key No. Part No. Description
Electrical Parts List
Note: Parts order must contain Chassis No., Part No., and Descriptions.
ASSEMBLED BOARDS
!A1000 655 003 1228 ASSY,PWB,MAIN KB8AC
!A1001 655 003 1211 ASSY,PWB,R/C
!A1002 655 003 2485 ASSY,PWB,TEMP KB8AC
!A2000 655 003 1204 ASSY,PWB,AV
!A690 655 003 1198 ASSY,PWB SW
!A600 655 003 1174 ASSY,PWB,POWER
!A630 655 003 1167 ASSY,PWB,LINE FILTER
OUT OF CIRCUIT BOARD
!A901 645 093 3134 UNIT,BALLAST+CV
L901 945 023 4959 CORE,CLAMP
!LF901 645 091 5765 UNIT,NOISE FILTER
!LP900 610 333 9740 COMPL,OPTICAL LAMP KM6AC
!FN901 645 101 9660 MOTOR,FAN DC
!FN902 645 101 9660 MOTOR,FAN DC
!FN903 645 095 8953 MOTOR,BLW DC
!FN904 645 100 1887 MOTOR,BLW DC
!FN905 945 079 2145 MOTOR,BLW DC
!FN907 945 079 2145 MOTOR,BLW DC
SP901 652 002 3055 SPEAKER,8
652 002 4397 SPEAKER,8
!SW902 945 048 3159 SWITCH,THERMAL(100DEG)
655 003 1228 ASSY,PWB,MAIN KB8AC
TRANSISTOR
Q1012 406 021 7804 TR 2SC4617
Q1021 406 021 7804 TR 2SC4617
Q1031 305 217 7815 TR HN1B04FE-Y TE85L
Q1041 305 217 7815 TR HN1B04FE-Y TE85L
Q1051 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q1061 406 021 7804 TR 2SC4617
Q1062 406 021 7804 TR 2SC4617
Q1421 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q1422 406 021 7804 TR 2SC4617
Q2001 406 021 7804 TR 2SC4617
Q2011 406 021 7804 TR 2SC4617
Q2021 406 021 7804 TR 2SC4617
Q2071 406 021 7804 TR 2SC4617
Q2371 305 217 6917 TR TPC6107 TE85L
Q2372 406 021 7804 TR 2SC4617
Q3582 305 217 6917 TR TPC6107 TE85L
Q3583 406 021 7804 TR 2SC4617
Q3601 406 021 7804 TR 2SC4617
Q3602 406 021 7804 TR 2SC4617
Q3801 305 191 5814 TR 3LN01C-TB-E
Q5031 405 221 7914 TR HN1C01FE-Y
Q5033 406 021 7804 TR 2SC4617
Q5035 405 221 7914 TR HN1C01FE-Y
Q5061 405 221 7914 TR HN1C01FE-Y
Q5062 405 221 7914 TR HN1C01FE-Y
Q5702 305 047 9010 TR 2SB1204-S-TL-E
Q5703 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q5751 305 217 6917 TR TPC6107 TE85L
Q5752 406 021 7804 TR 2SC4617
Q6841 405 221 7914 TR HN1C01FE-Y
Q6843 405 221 7914 TR HN1C01FE-Y
Q7801 405 221 7914 TR HN1C01FE-Y
Q7802 405 221 7914 TR HN1C01FE-Y
Q7812 305 217 8515 TR RSQ025P03-TR
Q7813 305 217 7815 TR HN1B04FE-Y TE85L
Q7814 305 217 7815 TR HN1B04FE-Y TE85L
Q7842 305 217 7815 TR HN1B04FE-Y TE85L
Q7862 305 217 8515 TR RSQ025P03-TR
Q7864 305 217 7815 TR HN1B04FE-Y TE85L
INTEGRATED CIRCUIT
IC1031 409 697 3913 IC LE24C023M-TLM-E
IC1051 409 697 3913 IC LE24C023M-TLM-E
IC1303 310 479 4004 IC TC7WBD125AFK
IC1371 410 656 8600 IC 24AA64T-I/MS
IC1422 309 431 4424 IC M62334FP-DF5Q
IC1424 410 666 5804 IC UPC358GR-9LG-E1-A
IC2301 409 700 7013 IC PW610-10GX
IC2371 409 685 9415 IC MP2307DN
IC2381 309 673 9819 IC PQ070XNA1ZPH
IC2391 310 595 8009 IC PQ1LAX95MSPQ
IC301 309 670 8419 IC PW190-10L
IC302 309 487 5727 IC TC7SZ125FU
IC3801 409 699 2815 IC MAX232ECPWR
IC3852 309 246 9710 IC LA6358NM-TE-L-E
IC4891 309 395 5915 IC TC7SH00FU-(TE85L)
IC5001 409 683 5716 IC NJW1156AV
IC5031 309 594 1916 IC LM4889MMX
IC5061 309 578 6210 IC PQ1M505M2SPQ
IC5081 309 578 6210 IC PQ1M505M2SPQ
IC5542 410 656 8501 IC XC6216BC02MR
IC5621 410 651 0104 IC R1131D101B-TR-F
IC5821 409 689 2115 IC MP2106DK
IC5841 309 598 5217 IC TAR5S25
IC5861 409 689 2115 IC MP2106DK
IC592 309 461 7822 IC PQ20WZ11
IC7811 309 675 1316 IC FA7703V-H1
IC7841 309 461 7822 IC PQ20WZ11
IC801 410 693 5105 IC M29W640FT70N6EKB8AC
IC841 410 647 7902 IC MCP103T-300
IC8801 410 696 5201 IC PIC18F67J60-I/PT-KB8AC
IC8802 410 656 8600 IC 24AA64T-I/MS
IC8803 410 681 5506 IC LE25FU106BMA-TLM-H
CAPACITOR
C1011 303 454 0415 CERAMIC 0.068U K 16V
303 442 0519 CERAMIC 0.068U K 16V
C1013 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
