Sanyo PLC-XU106

-61-
Control Port Functions
Scaler I/O Port Functions (PW190)
PIN
NO.
PORT
NO.
PORT NAME FUNCTION
SIGNAL
NAME
DESCRIPTION I/O
1 A1 PORTD7 DDC_SW3 DDC_SW3 DDC_SW3 O
188 G2 IN1G7 ON_33V 3.3V Power Drive, Power On: H O
349 H4 IN1B6 DDC_SW1 DDC_SW1 DDC_SW1 O
97 E1 IN1G2 ON_50V 5V Drive On/Off, On: H O
111 B12 PORTC1 SCS_PW 3-Wired Serial Control O
124 B25 TXD_PW TXD_PW Serial Control TXD O
201 C11 PORTC7 ON_150V 15V Power Driver, Power On: H O
202 C12 PORTC2 SDATA_PW 3-Wired Serial Control Data O
208 C18 TWOWSD2 2-Wire Serial Data 2 SDA2 IIC Bus Control Data O
211 C21 TWOWSC1 2-Wire Serial Clock 1 SCL IIC Bus Control Clock O
212 C22 TWOWSD0 2-Wire Serial Data 0 SDA IIC Bus Control Data O
28 C26 ADC1 ADC1 KEY1 Key Control Input I
344 N4 PORTC7 MUTE Sound Mute Drive, Mute On: H O
288 D15 DHS DHS PW_DHS H-Sync. Output O
290 D17 TWOWSC2 2-Wire Serial Clock 2 SCL2 IIC Bus Control Clock O
293 D20 TWOWSC0 2-Wire Serial Clock 0 SCL0 IIC Bus Control Clock O
294 D21 TWOWSD1 2-Wire Serial Data 1 SDA1 IIC Bus Control Data O
190 E2 FAN_SW1 FAN_SW1 Fan Control Switch O
215 D24 ADC0 ADC0 P_FAIL Power Failure Signal Input, Failure:L I
126 D25 ADC2 ADC2 KEY2 Key Control Input I
29 D26 ADC6 ADC6 LAMP Option Lamp Option I
362 E14 PORTC4 IRM_RST L3E07110 Reset O
368 E20 RXD_PW RXD_PW Serial Control RXD I
370 E22 ADC5 P_FAIL_FAN Power Failure Signal Input, Failure:L I
373 H22 DAC0 DAC0 FAN_CON_C Fan C Voltage Control O
298 F23 ADC4 ADC4 BRAND Option Option Switch BRAND I
128 F25 DAC2 DAC2 FAN_CON_B Fan B Voltage Control O
284 D11 PORTB4 BLAST_AC Lamp Cotrol, Lamp On:H O
99 C1 IN1R5 READY_LED READY LED Drive, On: H O
276 D3 IN1R3 TEMP_LED Temp Driver On: H O
352 E4 IN1R4 Lamp_LED LAMP REPLACE LED Drive, On: H O
353 E5 IN1R2 POWER_LED POWER LED Drive, On: H O
