Sanyo PLC-XU115 Service Manual

-4-
Specifications
This symbol on the nameplate means the product is Listed by Underwriters
Laboratories Inc. It is designed and manufactured to meet rigid U.L. safety stan-
dards against risk of fire, casualty and electrical hazards.
Mechanical Information
Projector Type Multi-media Projector
Dimensions (W x H x D) 334 mm x 78 mm x 262 mm (Not including adjustable feet)
Net Weight 3.7 kg
 FeetAdjustment 0˚to8.9˚  
Panel Resolution
LCD Panel System 0.8” TFT Active Matrix type, 3 panels
Panel Resolution 1,024 x 768 dots
Number of Pixels 2,359,296 (1,024 x 768 x 3 panels)
Signal Compatibility
Color System PAL, SECAM, NTSC, NTSC4.43, PAL-M, and PAL-N
High Definition TV Signal 480i, 480p, 575i, 575p, 720p, 1035i, and 1080i
Scanning Frequency H-sync. 15 kHz–100 kHz, V-sync. 50–100 Hz
Optical Information
Projection Image Size (Diagonal) Adjustable from 40” to 300”
Throw Distance 3.1' (0.93m) - 37.6' (11.47m)
Projection Lens F1.7–2.5 lens with f=19.2 mm–30.2 mm with manual zoom and focus
Projection Lamp 275 W
Interface
Video Input Jack RCA Type x 1
S-video Input Jack Mini DIN 4 pin x 1
Audio Input Jacks RCA Type x 2
Computer Input 1/DVI-I Input Terminal DVI-I Terminal X 1
Computer Input 2/Component Input Terminal Mini D-sub 15 pin X 1
Monitor Output Terminal Mini D-sub 15 pin x 1
Computer/Component Audio Input Jack Mini Jack (stereo) x 1
Service Port Connector Mini DIN 8 pin x 1
USB Connector USB Series B connector x 1
Audio Output Jack Mini Jack (stereo) x 1 (variable)
LAN Connection Terminal 100 Base-TX (100Mbps)/10 Base-T (10Mbps), RJ45
SD Card Slot
Audio
Internal Audio Amp 1.0 W RMS
Built-in Speaker 1 speaker, ø28 mm
Power
Voltage and Power Consumption AC 100–120 V (4.0A Max. Ampere), 50/60 Hz (The U.S.A and Canada)
AC 200–240 V (2.0A Max. Ampere), 50/60 Hz (Continental Europe and The U.K.)
Operating Environment
 OperatingTemperature 41˚F–95˚F(5˚C–35˚C)
 StorageTemperature 14˚F–140˚F(-10˚C–60˚C)
Remote Control
Battery AAA or LR03 Type x 2
OperatingRange 5m/±30˚
Dimensions 45 mm (W) x 23 mm (H) x 145 mm (D)
Net Weight 99 g (including batteries)
Laser Pointer
Class II Laser (Max. Output: 1 mW/Wave length: 640–660 nm)
●The specifications are subject to change without notice.
●LCD panels are manufactured to the highest possible standards. Even though 99.99% of the pixels are effective, a
tiny fraction of the pixels (0.01% or less) may be ineffective by the characteristics of the LCD panels.

Sanyo PLC-XU115 Specifications

General

Projection distance	0.93/11.47 m
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	500:1
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	-40 - 40 °
I/O ports	SD Card Slot
Audio input	1
Aspect ratio	4:3
Special features	Soft Carry Bag
Networking features	Ethernet & Wireless
F-number (relative aperture)	1.7
Lamp type	NSH
Lamp power	275 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Dot clock scanning frequency	140 MHz
Analog signal format system	NTSC, PAL, SECAM
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (typical)	266 W

Weight and Dimensions

Package weight	3500 g
