-63-
I/O Expander Port Functions (TE7783)
PIN NO. NAME FUNCTION ACTION I/O
5 P4 LEDN I
6 P5 W_R/C_SW L: Wired R/C I
34
WAKEUP
WAKEUP I
36 RST REST I
38 XI XI X'TAL IN I
39 XO XO X'TAL OUT O
43
XSTDBYE
XSTDBYEN O
48 P21 MCI_ON H: MCI ON O
50 P23 POWER_ON_MCI H: MCI ON O
54 P27 USB_VBUS
55 P28 USB_D- I/O
61 AIN1 P_FAIL_MCI Fpower Fail SIgnal Input for MCI Circuit I
67 AIN7 G-Sensor Input I
68 AIN8 G-Sensor Input I
72 P31 TXD_MCI For MCI O
73 P32 RXD_MCI For MCI I
74 P33 TXD2_MCI For MCI I
75 P34 RXD2_MCI For MCI O
81 DMNUS USD_D- I/O
91 P11 SIPD For DVI O
92 P12 SIPD0 For DVI O
93 P13 DVI_HPD For DVI O
94 P14 SIRST For DVI O
99
DDC_SW4
DDC_SW4 Switch for DDC IC O
Control Port Functions
To Next Page
