Sanyo PLC-XU116 Service Manual

KC8-XU11600
-103-
Mechanical Parts List
CABINET PARTS
C01 610 331 6413 ASSY,STAND LEG-KM6A
C02 610 345 9158 BUTTON-KY7AC
C03 610 349 6283 CABINET TOP-KC8AC
C04 610 345 3538 CABINET FRONT-KY7AC
C05 610 346 5586 CABINET BTM-KB8AC
C06 610 336 2434 CAP LENS-KB3AC
C07 610 333 8798 COVER ,LP SERVICE-KM6AC
C08 610 338 3682 FILTER BASE -KF3AC
C09 610 333 9207 DEC INLAY LED-KL6AC
C10 910 325 2477 DEC LEG-PT5EC
C11 910 302 5613 DEC SHEET-M4JA
C12 610 333 9290 FILTER BASE-KM6AC
C13 610 347 5639 GRILLE-KB8AC
C14 945 047 8032 BADGE,SANYO*26.2X5.7L26.0
C15 610 345 3521 DEC INLAY LED FR-KY7AC
CHASSIS PARTS
M01 610 348 3948 DEC AV SHEET-KC8AC
M02 610 334 4348 HOLDER POWER PWB BTM-KM6AC
M03 610 334 5895 HOLDER T SW-KM6AC
M04 610 344 6837 MOUNTING MCI-KY7AC
M05 610 346 5609 MOUNTING DUCT BTM-KB8AC
M06 610 346 5616 MOUNTING DUCT TOP-KB8AC
M07 610 334 4386 MOUNTING DUCT LP-KM6AC
M08 610 348 3924 PANEL AV-KC8BC
M09 610 334 0067 SPACER SHEET#POWER T-KM6AC
M10 610 334 7097 SPACER SHEET#POW T TOP-KM6AC
610 343 0348 SPACER SHEET#POW T TOP-KM6AC
M11 610 331 1692 OPTICAL BASE BTM-KM6A
M12 610 331 1715 OPTICAL BASE TOP A-KM6A
M13 610 331 1722 OPTICAL BASE TOP B-KM6A
M14 610 347 0542 SPACER SHEET LENS-KY7AC
SCREWS
S01 411 179 8801 SCR S-TPG BIN 3X10
S02 411 077 8606 SCR TPG FLT 3X8
S03 411 189 6507 BOLT HEX-SCT+SW+W 2.5X5
S04 312 070 3400 SPECIAL SCREW-3.0X10V
S05 312 069 7105 SPECIAL SCREW V
OPTICAL PARTS
L01 610 348 5584 ASSY PNL/PSM-KB8AC
(Including Key No. L01-1R to L01-2B and LCD panel)
L01-1R 645 089 3506 POLARIZED GLASS(OUT/R)
L01-1G 645 101 1428 POLARIZED GLASS(OUT/G)
L01-1B 645 089 3520 POLARIZED GLASS(OUT/B)
L01-2R 645 101 6690 PRE-POLARIZED GLASS(OUT/R)
L01-2G 645 101 1411 PRE-POLARIZED GLASS(OUT/G)
L01-2B 645 097 3918 PREPOLARIZED GLASS(OUT/B)
L02-R 645 089 3476 POLARIZED GLASS(IN/R)
L02-G 645 101 1435 POLARIZED GLASS(IN/G)
L02-B 645 089 3490 POLARIZED GLASS(IN/B)
L03 645 092 9892 PRISM(PBS)
645 096 4893 PRISM(PBS)
L04 645 102 1762 LENS,PROJECTION
L05 945 088 7797 LENS,INTEGRATOR(IN)
L06 945 088 7803 LENS,INTEGRATOR(OUT)
L07 945 088 7827 LENS,CONDENSER(OUT)
L08 945 088 7834 LENS,CONDENSER(G)
L09 945 088 7841 LENS,CONDENSER(B)
L10 945 088 7858 LENS,CONDENSER(R)
L11 945 088 7865 LENS,RELAY(IN)
L12 945 088 7872 LENS,RELAY(OUT)
L13 945 088 7889 MIRROR(B)
L14 945 088 7896 MIRROR(R)
L15 945 088 7902 DICHROIC MIRROR (B)
L16 945 088 7919 DICHROIC MIRROR (G)
Key No. Part No. Description
Key No. Part No. Description
Mechanical Parts List
Note: Parts order must contain Chassis No., Part No., and Descriptions.
