KC8-XU11600
-71-
Electrical Parts List
Key No. Part No. Description Key No. Part No. Description
Electrical Parts List
Note: Parts order must contain Chassis No., Part No., and Descriptions.
ASSEMBLED BOARDS
!A630 655 003 1167 ASSY,PWB,FILTER KB8AC
!A600 655 003 5226 ASSY,PWB,POWER KC8AC
!A100 655 003 3390 ASSY,PWB,NETWORK KC8AC
!A200 655 003 3383 ASSY,PWB,ANTNA KC8AC
!A1000 655 003 3369 ASSY,PWB,MAIN
!A1001 655 003 3352 ASSY,PWB,R/C
!A1002 655 003 3345 ASSY,PWB,TMP
!A2000 655 003 3321 ASSY,PWB,AV
!A690 655 003 3314 ASSY,PWB,SW
OUT OF CIRCUIT BOARD
!A901 645 093 3134 UNIT, BALLAST+CV
L901 945 023 4959 CORE,CLAMP
!LF901 645 091 5765 UNIT,NOISE FILTER
!LP900 610 333 9740 COMPL,OPT LMP-KM6AC
!A902 645 102 7245 ADAPTOR,WIRELESS LAN
!FN901 645 101 9660 MOTOR,FAN DC 3.36W
!FN902 645 101 9660 MOTOR,FAN DC 3.36W
!FN903 645 095 8953 MOTOR,BLW DC 1.92W
!FN904 645 100 1887 MOTOR,BLW DC ***W
!FN905 945 079 2145 MOTOR,BLW DC 2.76W
!FN907 945 079 2145 MOTOR,BLW DC 2.76W
SP901 652 002 3055 SPEAKER,8
652 002 4397 SPEAKER,8
!SW902 945 048 3159 SWITCH,THERMAL(100DEG)
Z8002 652 003 1265 CORD,SHIELD
655 003 1167 ASSY,PWB,FILTER KB8AC
CAPACITOR
!C601 404 113 2904 MT-POLYEST 0.33U K 275V
!C602 404 113 2904 MT-POLYEST 0.33U K 275V
RESISTOR
!R600 401 353 0212 MT-GLAZE 360K JA 1/3W
!R601 401 353 0212 MT-GLAZE 360K JA 1/3W
VARIABLE RESISTOR
!VA601 308 061 5607 VARISTOR ENE471D-14A-S6
408 061 9701 VARISTOR S14K300E2S5M4,2
COIL
!L601 945 050 2232 LINE FILTER
MISCELLANEOUS
!F601 323 025 1204 FUSE 250V 8A
655 003 5226 ASSY,PWB,POWER KC8AC
TRANSISTOR
Q611 305 217 6600 TR 2SK3934
Q612 305 217 6600 TR 2SK3934
Q621 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q622 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q641 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q642 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q643 305 217 6600 TR 2SK3934
Q651 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q661 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
INTEGRATED CIRCUIT
IC621 409 690 7918 IC FA5550N
IC631 309 653 7405 IC MR4010-7101
IC671 409 692 2515 IC TA76L431FB
CAPACITOR
C611 303 222 1326 CERAMIC 1000P K 1K
304 084 6300 CERAMIC 1000P K 1K
C612 303 222 1326 CERAMIC 1000P K 1K
304 084 6300 CERAMIC 1000P K 1K
C613 303 451 4119 MT-POLYEST 1U K 450V
C614 303 451 4119 MT-POLYEST 1U K 450V
C615 404 115 2704 ELECT 330U M 420V
404 115 6306 ELECT 330U M 420V
C621 303 336 3510 CERAMIC 0.47U K 16V
C622 304 091 4504 CERAMIC 0.047U K 50V
C623 304 090 1207 CERAMIC 0.01U K 50V
C625 304 090 1108 CERAMIC 1000P K 50V
C626 303 396 9613 CERAMIC 1U K 25V
403 478 5912 CERAMIC 1U K 25V
C627 304 091 3309 CERAMIC 2200P K 50V
C629 303 265 3216 CERAMIC 1000P J 50V
C631 303 157 4215 CERAMIC 220P J 50V
C632 303 245 4417 CERAMIC 470P K 2K
To Next Page
