Sanyo PLC-XU116 Service Manual

-24-
 ●: Adjustment necessary ❍: Check necessary
Adjustments after Parts Replacement
Adjustments
Disassembly / Replaced Parts
LCD/
Prism Ass’y
Integrator
Lens (IN)
Relay
Lens (OUT)
Polarized Glass
Power Board Main Board
R G B
Optical Adjustments
Contrast Adjustment
R-Contrast adjustment
●
G-Contrast adjustment
●
B-Contrast adjustment
●
Integrator lens adjustment
❍ ●
Relay lens-out adjustment
❍ ●
Electrical Adjustments
Fan control adjustment
● ●
Panel type check and setting
● ●
Reference Voltage adjustment
●
Auto calibration adjustment [PC]
●
Auto calibration adjustment
[Component]
●
Auto calibration adjustment
[Video]
●
Common center adjustment
● ●
Keystone offset adjustment
●
White uniformity adjustment
❍ ❍
