Sanyo PLC-XU116 Service Manual

-50-
Electrical Adjustments
Group/
Item
Item Name Function Initial Range Note
8 VSBEG 2 0 - 15
Group
561
HDCP (575P)
7 Over Scan
Over Scan Rate (0 ~ 25.5% at 0.1%
steps)
0 0 - 255
8 VSBEG 2 0 - 15
Group
562
HDCP (720P-60)
7 Over Scan
Over Scan Rate (0 ~ 25.5% at 0.1%
steps)
0 - 255
8 VSBEG 2 0 - 15
Group
563
HDCP (720P-50)
7 Over Scan
Over Scan Rate (0 ~ 25.5% at 0.1%
steps)
0 0 - 255
8 VSBEG 2 0 - 15
Group
564
HDCP (1080i-60)
7 Over Scan
Over Scan Rate (0 ~ 25.5% at 0.1%
steps)
0 0 - 255
8 VSBEG
2 0 - 15
Group
565
HDCP (1080i-50)
7 Over Scan
Over Scan Rate (0 ~ 25.5% at 0.1%
steps)
0 0 - 255
8 VSBEG 2 0 - 15
Group
566
HDCP (1035i)
7 Over Scan
Over Scan Rate (0 ~ 25.5% at 0.1%
steps)
0 0 - 255
8 VSBEG 2 0 - 15
Group
981
Color Shading Adj Offset
0 R-Max 0/0 0-255
1 R-Mid1 0/0 0-255
2 R-Mid2 0/0 0-255
3 R-Min 0/0 0-255
4 G-Max 0/0 0-255
5 G-Mid1 0/0 0-255
6 G-Mid2 0/0 0-255
7 G-Min 0/0 0-255
8 B-Max 0/0 0-255
9 B-Mid1 0/0 0-255
10 B-Mid2 0/0 0-255
11 B-Min 0/0 0-255
