Sanyo PLC-XU116 - Page 78

Key No. Part No. Description Key No. Part No. Description
KC8-XU11600
Electrical Parts List
-78-
L8010 945 086 6037 IMPEDANCE,330 OHM P
L8015 945 062 2930 INDUCTOR,10U M
L8016 945 062 2930 INDUCTOR,10U M
L8017 945 075 1388 INDUCTOR,10U M
L8080 945 070 3660 INDUCTOR,90 OHM
L8088 945 070 3660 INDUCTOR,90 OHM
DIODE
D8005 307 210 1923 DIODE 1SS400 TE-61
D8006 307 210 1923 DIODE 1SS400 TE-61
D8007 307 210 1923 DIODE 1SS400 TE-61
D8008 307 210 1923 DIODE 1SS400 TE-61
D8009 307 228 1011 LED SML-310MT-M-T86
D8010 307 228 1011 LED SML-310MT-M-T86
D8011 307 228 1011 LED SML-310MT-M-T86
D8012 307 210 1923 DIODE 1SS400 TE-61
D8013 307 210 1923 DIODE 1SS400 TE-61
D8014 307 210 1923 DIODE 1SS400 TE-61
D8015 307 210 1923 DIODE 1SS400 TE-61
D8016 307 210 1923 DIODE 1SS400 TE-61
D8017 307 210 1923 DIODE 1SS400 TE-61
D8018 307 210 1923 DIODE 1SS400 TE-61
D8019 307 210 1923 DIODE 1SS400 TE-61
MISCELLANEOUS
K8001 652 002 4540 SOCKET,USB 4P
K8015 645 093 6760 TRANS,PULSE
X8001 645 102 6934 OSC,CRYSTAL 27.000MHZ
X8002 945 037 4600 OSC,CRYSTAL 32.768KHZ
655 003 3383 ASSY,PWB,ANTNA KC8AC
K8006 SOCKET USB 4P
652 002 4540 SOCKET,USB 4P
655 003 3369 ASSY,PWB,MAIN
TRANSISTOR
Q1012 406 021 7804 TR 2SC4617
Q1021 406 021 7804 TR 2SC4617
Q1031 305 217 7815 TR HN1B04FE-Y TE85L
Q1041 305 217 7815 TR HN1B04FE-Y TE85L
Q1051 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q1061 406 021 7804 TR 2SC4617
Q1421 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q1422 406 021 7804 TR 2SC4617
Q2001 406 021 7804 TR 2SC4617
Q2011 406 021 7804 TR 2SC4617
Q2021 406 021 7804 TR 2SC4617
Q2071 406 021 7804 TR 2SC4617
Q2371 305 217 6917 TR TPC6107 TE85L
Q2372 406 021 7804 TR 2SC4617
Q3582 305 217 6917 TR TPC6107 TE85L
Q3583 406 021 7804 TR 2SC4617
Q3601 406 021 7804 TR 2SC4617
Q3602 406 021 7804 TR 2SC4617
Q5031 405 221 7914 TR HN1C01FE-Y
Q5033 406 021 7804 TR 2SC4617
Q5035 405 221 7914 TR HN1C01FE-Y
Q5061 405 221 7914 TR HN1C01FE-Y
Q5062 405 221 7914 TR HN1C01FE-Y
Q5611 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q5751 305 217 6917 TR TPC6107 TE85L
Q5752 406 021 7804 TR 2SC4617
Q6833 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q6841 405 221 7914 TR HN1C01FE-Y
Q6843 405 221 7914 TR HN1C01FE-Y
Q6844 406 021 7804 TR 2SC4617
Q7801 405 221 7914 TR HN1C01FE-Y
Q7812 305 217 8515 TR RSQ025P03-TR
Q7813 305 217 7815 TR HN1B04FE-Y TE85L
Q7814 305 217 7815 TR HN1B04FE-Y TE85L
Q7842 305 217 7815 TR HN1B04FE-Y TE85L
Q7862 305 217 8515 TR RSQ025P03-TR
Q7864 305 217 7815 TR HN1B04FE-Y TE85L
INTEGRATED CIRCUIT
IC1051 409 697 3913 IC LE24C023M-TLM-E
IC1303 310 479 4004 IC TC7WBD125AFK
IC1371 410 656 8600 IC 24AA64T-I/MS
IC1422 309 431 4424 IC M62334FP-DF5Q
IC1424 410 666 5804 IC UPC358GR-9LG-E1-A
IC1701 410 699 1804 IC TC7USB221FT(EL)
IC1802 309 671 7817 IC TE7783APF
309 633 6117 IC TE7783PF
IC213 309 670 5517 IC TC7SH125FE(TE85L,F)
IC214 309 670 5517 IC TC7SH125FE(TE85L,F)
IC2301 409 700 7013 IC PW610-10GX
IC2371 409 685 9415 IC MP2307DN
IC2381 409 699 6615 IC BD7820FP
IC2391 409 699 6516 IC TA48S00AF
IC301 309 670 8419 IC PW190-10L
IC3801 309 495 2517 IC SP3232ECY/TR
IC3852 309 246 9710 IC LA6358NM-TE-L-E
IC4891 309 395 5915 IC TC7SH00FU-(TE85L)
IC5001 409 683 5716 IC NJW1156AV
IC5031 309 594 1916 IC LM4889MMX
IC5061 309 578 6210 IC PQ1M505M2SPQ
IC5542 410 656 8501 IC XC6216BC02MR
IC5603 309 578 6210 IC PQ1M505M2SPQ
IC5621 410 651 0104 IC R1131D101B-TR-F
IC5821 409 689 2115 IC MP2106DK
IC5841 309 598 5217 IC TAR5S25
IC5861 409 689 2115 IC MP2106DK
IC592 309 461 7822 IC PQ20WZ11
IC7001 409 698 5510 IC SII9127ACTU
IC7811 309 675 1316 IC FA7703V-H1
IC7841 309 461 7822 IC PQ20WZ11
IC801 410 699 5802 IC M29W640FT70N6E-KC8AC
IC8081 409 699 6516 IC TA48S00AF
