COMPUTER IN 1 /COMPONENT IN /COMPUTER IN 2/MONITOR OUT (ANALOG)
Terminal: Analog RGB (Mini D-sub 15 pin)
5
1
2
34
10
9 678
15
14
13
1112
Configurations of Terminals
Red (R/Cr) Input/Output
Ground (Horiz.sync.)
Green (G/Y) Input/Output
-----
Blue (B/Cb) Input/Output
Ground (Red)
Ground (Green)
Ground (Blue)
1
5
2
4
3
6
7
8
+5V Power/-----
Horiz. sync. Input/Output (Composite H/V sync.)
Ground (Vert.sync.)
DDC Data
/-----
Ground/-----
Vert. sync.
DDC Clock
/-----
9
13
10
12
11
14
15
RX –
TX +
TX –
RX +
2
3
4
87654321
5
6
7
8
1
LAN TERMINAL
-----
-----
----------
CONTROL PORT CONNECTOR (D-sub 9 pin)
-----
RXD
TXD
-----
SG
-----
RTS
CTS
Serial
1
2
3
4
5
6
7
8
-----9
