Sanyo SPW-C1903GDYH8 User Manual

W-ECO MULTI SYSTEM Unit Spesifications
TD831077
IV - 22
4
1. Outdoor Unit
1-4. Refrigerant flow diagram
SPW-CR1503GDYH8, SPW-CR1903GDYH8, SPW-C1503GDYH8, SPW-C1903GDYH8
PC
compressor
AC
compressor
SC
compressor
LIVS
TH1
TH2
TH3
TH8 TH7
TH6
Accumulator
Accumulator
LIVP
LIVA
Balance tube
ø9.52
Narrow tube
150 type: ø15.88
190 type: ø19.05
Wide tube
Low pressure
switch
150 type: ø38.1
190 type: ø41.28
High
pressure
switch
High
pressure
switch
Oil
separator
High
pressure
switch
OILS
valve
SAVE
valve
DFV
valve
Heat exchanger
Coil2
(Left)
Coil1
(Right from front side)
P
Receiver
tank
Fusible
plug
High pressure
port
OILP
valve
ORVR
valve
BALV
valve
4-way valve
BPV
valve
RCV
valve
HP
1764_C_I
LPV
valve
∗
HPV
valve
HP
LP
HP
( )
( )
( )
( )
( )
( )
( )
TH9
TH5 TH4
MOV2
MOV1
CM
CM
CM
∗
∗

Sanyo SPW-C1903GDYH8 Specifications

General

Type	Split System
Power Supply	220-240V, 50Hz
Refrigerant	R410A
Cooling Capacity	19000 BTU/h
Operating Temperature (Cooling)	18°C to 43°C
Operating Temperature (Heating)	-15°C to 24°C
