IV - 39
TD831077
4
W-ECO MULTI SYSTEM Unit Specifications
3-1. Specifications
Unit specifications (A)
3. 2-Way Air Discharge Semi-concealed Type
MODEL No. Indoor Unit SPW-SR93GH56 / SPW-S93GH56
POWER SOURCE 220 - 230 - 240 V / 1 phase / 50Hz
PERFORMANCE Cooling Heating
Capacity kW 2.8 3.2
BTU / h 9,600 11,000
Air circulation (Hi / Me / Lo) m
3
/h 540 / 485 / 410
Moisture removal (High) Liters/h 1.0 —
ELECTRICAL RATINGS
Voltage rating VAC 220 - 230 - 240
Available voltage range VAC 198 – 264
Running amperes A 0.33 - 0.34 - 0.35 0.24 - 0.25 - 0.26
Power input W 70 - 75 - 80 50 - 55 - 60
Power factor % 96 - 96 - 95 95 - 96 - 96
Fan motor locked rotor amperes A 1 - 1 - 1
FEATURES
Controls Microprocessor
Timer ON / OFF Timer (Max. 72 hr)
Fan speeds 3 and Automatic control
Air filter Washable, easy access, long life (2,500 hr)
Refrigerant control Electronic expansion valve
Operation sound (Hi / Me / Lo) dB-A 32 / 30 / 25
Refrigerant tubing connections Flare type
Refrigerant tube diameter Narrow tube mm (in.) 9.52 (3 / 8)
Wide tube mm (in.) 12.7 (1 / 2)
Drain connection 25 A, OD32 mm
Drain pump Max. head 25 cm above drain connection
Remote Controller Optional (RCS-SH80TG)
Refrigerant tubing kit / Accessories Optional / —
Color (Approximate value) Munsell 10Y9.3 / 0.4, RAL 9010-GL
DIMENSIONS & WEIGHT (include ceiling panel) Unit dimensions Package dimensions
Dimensions Height mm (in.) 398 ( 15 - 5 / 8) 519 (20 - 3 / 8)
Width mm (in.) 1,110 (43 - 3 / 4) 1,218 (48 - )
Depth mm (in.) 680 (26 - 3 / 4) 788 ( 31 - )
Net weight kg (lbs.) 40 ( 88 )
Shipping weight kg (lbs.) 61 ( 135 )
Shipping volume m
3
(cu. ft) 0.498 ( 17.6 )
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Rated conditions
Cooling: Indoor air temperature 27 °CDB/19 °C WB, Outdoor air temperature 35 °C DB
Heating: Indoor air temperature 20 °C DB , Outdoor air temperature 7 °CDB/6 °CWB
