W-ECO MULTI SYSTEM Unit Specifications
3-2. Major component specifications
Indoor unit (A)
3. 2-Way Air Discharge Semi-concealed Type
MODEL No. SPW-SR93GH56 SPW-S93GH56
Source 220 - 230 - 240 V / 1 phase / 50Hz
Controller P.C.B. Ass’y CR-X253GH (Microprocessor)
Fan (Number…diameter) mm Centrifugal (1 … ø 190)
Fan motor
Model…Nominal output W UF4X-31B3P ... 30 W
Source 220 - 230 - 240 V / 1 phase / 50 Hz
No. of pole…r.p.m. (230 V, High) rpm. 4P ... 540
Coil resistance Ω BRN – WHT : 139.3 ORG – YEL : 25.59
(Ambient temperature 20 °C) WHT – VLT : 19.77 YEL – BLK : 43.02
VLT – ORG : 38.20 BLK – PNK : 84.32
Safety device
Operating temperature Open °C 130 ± 5
Close °C (115 ± 5)
Run capacitor VAC, µF 440 VAC, 1.0 µF
Electronic expansion valve
Coil DKV-MOZS550E0
Coil resistance (at 20 °C) Ω ORG – GRY : 46 , YEL – GRY : 46
RED – GRY : 46, BLK – GRY : 46
Valve body IKV-24D12
Heat exchanger
Coil Aluminum plate fin / Copper tube
Rows…fin pitch mm 2…1.5 2…1.7
Face area m
2
0.265
Panel
Model No. PNR-S123GHA
Auto louver motor MT8-3C
Auto louver motor…Rated VAC, W, rpm. 200 ~ 240 VAC, 3 W, 2.5 rpm
Coil resistance (at 25 °C) Ω 16,430 Ω ± 8 %
Drain Pump WP20SL-18
Rated V, W AC230 V, 50 Hz, 14.7 W
Total head & capacity 400 mm, 600 cc/min
