IV - 55
TD831077
4
W-ECO MULTI SYSTEM Unit Specifications
4. 1-Way Air Discharge Semi-concealed Type
Indoor unit (B)
MODEL No. SPW-ASR123GH56 SPW-AS123GH56
Source 220 - 230 - 240 V / 1 phase / 50Hz
Controller P.C.B. Ass’y CR-X253GH (Microprocessor)
Fan (Number…diameter) mm Centrifugal (1 … ø 190)
Fan motor
Model…Nominal output W UE6Q-21B3P … 20 W
Source 220 - 230 - 240 V / 1 phase / 50 Hz
No. of pole…r.p.m. (230 V, High) rpm. 6P … 771
Coil resistance Ω BRN – WHT : 290.0 ORG – YEL : 241.2
(Ambient temperature 20 °C) WHT – VLT : 117.4 WHT – PNK : 45.74
VLT – ORG : 39.32
Safety device
Operating temperature Open °C 130 ± 5
Close °C (115 ± 5)
Run capacitor VAC, µF 440 VAC, 1.0 µF
Electronic expansion valve
Coil LAM-MDI2ST-1
Coil resistance (at 20 °C) Ω ORG – GRY : 48 , YEL – GRY : 48
RED – GRY : 48 , BLK – GRY : 48
Valve body LAM-B30YPST-1
Heat exchanger
Coil Aluminum plate fin / Copper tube
Rows…fin pitch mm 3 … 2.0
Face area m
2
0.144
Panel
Model No. PNR-AS123GH
Drain Pump WP20SL-14
Rated V, W AC 230 V, 50 Hz, 14.7 W
Total head & capacity 400 mm, 600 cc/min
