W-ECO MULTI SYSTEM Unit Specifications
6. Ceiling Mounted Type
Indoor unit (D)
MODEL No. SPW-TR483GH56
Source 220 - 230 - 240 V / 1 phase / 50Hz
Controller P.C.B. Ass’y CR-X253GH (Microprocessor)
Fan (Number…diameter) mm Centrifugal (4…ø150)
Fan motor
Model…Nominal output W KFG4X-101C6P…100 W
Source 220 - 230 - 240 V / 1 phase / 50 Hz
No. of pole…r.p.m. (230 V, High) rpm. 4…1,070
Coil resistance Ω BRN – WHT : 61.05 ORG – YEL : 13.23
(Ambient temperature 20°C) WHT – VLT : 9.955 YEL – BLK : 19.25
VLT – ORG : 9.576 BLK – PNK : 10.81
Safety device
Operating temperature Open °C 130 ± 8
Close °C(79± 15 )
Run capacitor VAC, µF 440 VAC, 5.0 µF
Electronic expansion valve
Coil EKV - MOZS584E0
Coil resistance (at 20°C) Ω ORG – GRY : 46 , YEL – GRY : 46
RED – GRY : 46 , BLK – GRY : 46
Valve body HKV - 30D16
Heat exchanger
Coil Aluminum plate fin / Copper tube
Rows…fin pitch mm 3…1.5
Face area m
2
0.326
Auto louver motor MT8 - 3C
Auto louver motor…Rated VAC, Hz, W, rpm. 220 – 240 VAC, 50Hz, 3 W, 3.3 rpm.
Coil resistance (at 25°C) Ω 16,430 Ω ± 8 %
