IV - 127
TD831077
4
W-ECO MULTI SYSTEM Unit Specifications
Unit specifications (B)
10. Concealed Floor-Standing Type (FM Type)
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Cooling :
Rating conditions(
*
) : Indoor air temperature 27 °C DB / 19 °C WB, Outdoor air temperature 35 °C DB
Heating :
Rating conditions(
*
) : Indoor air temperature 20 °C DB, Outdoor air temperature 7°C DB / 6°C DB
MODEL No. Indoor Unit SPW-FMR123GH56 / SPW-FM123GH56
POWER SOURCE 220 - 230 - 240 V / 1 phase / 50Hz
PERFORMANCE Cooling Heating
Capacity kW 3.6 4.2
BTU / h 12,000 14,000
Air circulation (Hi / Me / Lo) m
3
/ h 540 / 420 / 360
Moisture removal (High) Liters / h 1.7 –
ELECTRICAL RATINGS
Voltage rating VAC 220 - 230 - 240
Available voltage range VAC 198 – 264
Running amperes
*
A 0.37 - 0.38 - 0.39 0.3 - 0.31 - 0.32
Power input W 79 - 85 - 91 64 - 70 - 76
Power factor % 97.1 - 97.3 - 97.2 97 - 98.2 - 99
Max. starting amperes A 1 - 1 - 1
FEATURES
Controls Microprocessor
Timer ON / OFF Timer (Max.72 hr)
Fan speeds 3 and Automatic control
Air filter Washable, easy access
Refrigerant control Electronic expansion valve
Operation sound (Hi / Me / Lo) dB-A 39 / 35 / 29
Refrigerant tubing connections Flare type
Refrigerant tube Narrow tube mm (in) 9.52 (3 / 8)
outer diameter Wide tube mm (in) 12.7 (1 / 2)
Drain connection 20A, OD26mm
Drain pump –
Drain pump (drain connection) Optional (RCS-SH80TG)
Remote controller (option) Optional / drain hose
DIMENSIONS & WEIGHT Unit dimensions Package dimensions
Dimensions Height mm (in) 616 ( 24 - 8 /32) 679 (26 --23/32)
Width mm (in) 904 ( 35 - 19 /32) 976 (38 --14/32)
Depth mm (in) 229 ( 9 - 1 /32) 312 (12 - 9 /32)
Net weight kg (lb) 21 ( 64 )
Shipping weight kg (lb) 23 ( 51 )
Shipping volume m
3
(cu. ft) 0.207 ( 7.3 )
To Next Page
