IV - 145
TD831077
4
W-ECO MULTI SYSTEM Unit Specifications
Indoor unit (D)
MODEL No. SPW-SLR253GH56
Source 220 - 230 - 240 V / 1 phase / 50Hz
Controller P.C.B. Ass’y CR-X253GH (Microprocessor)
Fan (Number…diameter) mm Centrifugal (4)
Fan motor
Model…Nominal output W SFG4X - 51B5P... 30 W
Source 220 - 230 - 240 V / 1 phase / 50 Hz
No. of pole…r.p.m. (230 V, High) rpm. 4... 1,210
Coil resistance Ω WHT - BRN : 149.8 ORG - YEL : 35.66
(Ambient temperature 20 °C) WHT - VLT : 29.44 YEL - BLK : 40.72
VLT - ORG : 23.39 BLK - PNK : 3.780
Safety device
Operating temperature Open °C 130 ± 8
Close °C79± 15
Run capacitor VAC, µF 440 VAC, 2.0 µF
Electronic expansion valve
Solenoid control model DKV-MOZS550E0
Coil resistance (at 20 °C) Ω ORG – GRY : 46 , YEL – GRY : 46
RED – GRY : 46 , BLK – GRY : 46
Solenoid control valve model IKV-24D12
Heat exchanger
Coil Aluminum plate fin / Copper tube
Rows…fin pitch mm 3 … 1.5
Face area m
2
0.170
Panel
Model No. PNR-SL253GHA
Auto louver motor MT8-3C
Auto louver motor…Rated VAC, W, rpm. 220 - 240 VAC, 3 W, 3 rpm
Coil resistance (at 25 °C) Ω 16,430 Ω ± 8 %
Drain Pump WP20SL-19
Rated V, W AC230 V, 50 Hz, 14.7 W
Total head & capacity 400 mm, 600 cc/min
11. 1-Way Air Discharge Semi-concealed-Slim Type (SL Type)
